Sime MURELLE REVOLUTION 25 User, Installation And Servicing Instructions page 45

– turn the encoder to select "Heating"
– press the encoder to confirm "Heating" and access the
"Rows"
Function Mode
Set AUTO comfort
Set AUTO reduced
Set MAN
Program. Time
Esc
– press the click encoder to confirm the highlighted "Row"
and access the modifiable area
Function Mode
Set AUTO comfort
Set AUTO reduced
Set MAN
Program. Time
Esc
– turn the encoder to modify the "Data/value" in the
permitted field (e.g. MAN - AUTO - OFF)
– Press the click encoder to confirm any modifications made
and go back to the row "Function mode"
– turn the encoder to select another "Row" (e.g.
).
"Program. Time"
m
CAUTION
For information on using the functions "Time
Programming" and "Holiday function" see the
relevant section ("User instructions").
6.3.1.1 Fault warnings
If a fault occurs, the screen "Anomaly in progress" will appear
in place of the "Main screen" . For the main fault codes, a brief
description and suggestions for the user are displayed, based
on the seriousness and the frequency with which the fault
reappears.
ANOMALY IN PROGRESS
5 - Technical problem
Contact customer service
Name: xxxxxxxx
Phone:yyyyyyyyy
Esc Back
Heating
MAN
20.0°C
18.0°C
20.0°C
[...]
Back
Fig. 103
Heating
MAN
20.0°C
18.0°C
20.0°C
[...]
Back
Fig. 104
ANOMALY IN PROGRESS
6 - No flame detection
Reset boiler
Esc Reset
Fig. 105
The fault may be transient (volatile) or it may cause an appliance
.
block
To restore normal operating conditions:
– if the fault is transient, eliminate the cause of the fault
– if the fault causes a block, remove the cause of the fault and
then press the
Reset
If there is "no water in the system" or "low water pressure in the
system" there is a request to fill the system and then to press
the button rather than the
Confirm
ANOMALY IN PROGRESS
2 - Low pressure
Fill the system as per boiler's manual instruction
Esc Charge
A list of possible faults is given under "Fault / malfunction
codes".
6.3.1.2 Quick settings
The encoder allows the operator, specifically the user, to:
– change the "Set hot water" in SUMMER mode
– change the "Set room temperature" in WINTER mode.
In both cases, from the "Main screen" :
– press the click encoder to display the set value
HOT WATER SET
40.0
Set hot water
Cancel Confirm
– turn the encoder to set the new "Set value"
– press the button to complete the modification
Confirm
and return to the "Main screen" .
ROOM SET
21.3
Manual temporary
Cancel Confirm
IMPORTANT INFORMATION
TEMPERATURE
The meaning of the words on the display is as follows:
the heating "Function mode" is set to AUTO
Manual temporary:
and the set value read on the display is valid until the next time
band change (automatic set point)
the heating "Function mode" is set to MAN and the set
Manual:
value read on the display is permanently valid.
button.
button.
Reset
CONFIRM REQUEST
Confirm operation?
Cancel Confirm
Fig. 106
ROOM SET
21.3
Manual temporary
Cancel Confirm
Fig. 107
ROOM SET
21.3
Manual
Cancel Confirm
Fig. 108
FOR THE SET AMBIENT
45
