- Page 1 SOLO / DUETTO 25-35 ErP ISTRUZIONI PER L’INSTALLAZIONE E LA MANUTENZIONE Fonderie SIME S.p.A Cod. 6322896 - 09/2016...
- Page 2 INSTALLER INSTRUCTIONS CONTENTS DESCRIPTION OF THE BOILER ..........................INSTALLATION ..............................CHARACTERISTICS .............................. USE AND MAINTENANCE ........................... CONFORMITY Our Company declares that SOLO - DUETTO ErP boilers comply with the essential requirements of the following directives: - Boiler Efficiency Directive 92/42/EEC - Ecodesign Directive 2009/125/EC - Regulation (EU) N.
-
Page 3: Description Of The Boiler
DESCRIPTION OF THE BOILER INTRODUCTION The instructions relative to the fol- are provided to ensure proper instal- lowing models are indicated in the lation and perfect operation of the present manual: appliance and should be strictly follo- One of the features of the cast iron –... - Page 4 TECHNICAL FEATURES SOLO 25 ErP SOLO 35 ErP DUETTO 25 ErP DUETTO 35 ErP Heat output (Pn max) 25.2 32.7 25.2 32.7 Heat input (Qn max - Qnw max) 27.0 34.8 27.0 34.8 Measured yield 100% useful 93,9 94,0 93,9 94,0 Measured yield 30% useful 97,9...
- Page 5 MAIN COMPONENTS 1.4.1 “SOLO 25-35” version (fig. 2) 1 Gas-oil burner 2 Bulb housing sheath 3 Control panel 4 Filling 5 Water switch 6 Hydrometer 7 C.H. pump high efficiency 8 Air intake for airtight burner (type C) Fig. 2 1.4.2 “DUETTO 25-35”...
- Page 6 FUNCTIONAL DIAGRAM 1.5.1 “SOLO 25-35” version (fig. 3) 1 Boiler body 2 Filling 3 Safety valve 4 Air relief valve 5 Expansion vessel 6 Gas-oil burner 7 C.H. pump high efficiency 8 Hydrometer 9 Boiler drainer cock 10 Water switch Fig.
-
Page 7: Installation
INSTALLATION BOILER ROOM Upon completing the filling, put the more than 20°F. screw back to its original position. At In all cases the water used should be the end of the operation make sure tested and adequate treatment devi- The boilers with a rating of more than 35 kW must be equipped with a that the tap is closed (fig. - Page 8 When dimensioning the 2.3.2 Smoke exhaust with Only use original SIME accessories flue, the effective height of the ø 80/125 coaxial flue and make sure that connections are flue in meters must be consid- (type C) (fig.
- Page 9 passed through the aperture on the right or left hand side of the shell for TABLE 1 connection to the pump (fig. 7 - 7/a). L (meters) meters øi tube øi tube Important 8 mm 10 mm – Make sure, before turning on the boiler, that the return tube is free.
- Page 10 230V-50Hz single- Always turn off the power supply phase through a fused main switch. NOTE: Device must be connected to before doing any work on the electri- The stat cable, whose installation an efficient earthing system. SIME cal panel.
- Page 11 2.7.1 “SOLO 25-35” wiring diagram (fig. 9) Main switch TS Safety stat TC Boiler stat SPA Water pressure gauge triggered light SA Power on light SB Burner “lock out” warning light PA Water switch C.H. pump high efficiency Burner TA Room stat OP Time programmer NOTE: When connecting the room stat (TA) remove the brid-...
- Page 12 2.7.2 “DUETTO 25-35” wiring diagram (fig. 9/a) Main switch Relay TM Minimum tem. stat TL Limit stat VP Pressure stat valve TS Safety stat E/I Summer/Winter switch TC Boiler stat SPA Water pressure gauge triggered light SA Power on light SB Burner “lock out”...
-
Page 13: Characteristics
2.7.3 Functional diagram Normal Stopped due to failure to ignite Thermostat Resistance Motor Ignition transformer Gas-oil valve Flame Lock-out lamp 0÷150 s ~ 12 s 0÷150 s ~ 12 s ~ 5 s CHARACTERISTICS COMBUSTION CHAMBER DIMENSIONS (fig. 10) The combustion chamber is a direct passage type and is conform to the EN 303-3 standard annex E. - Page 14 Pump high efficiency diagnose and remedy (fig. 11/a) Signal LED LED diagnose and remedy Led color Meaning Diagnostic Cause Remedy Continuous green Normal running Pump run as Normal operation expected or is faced to a phenomenon that shortly affects its running Red/green blinking Abnormal situation Pump will restart...
-
Page 15: Use And Maintenance
USE AND MAINTENANCE DISASSEMBLY OF OUTER CASING (fig. 14) The shell can be completely disas- sembled for an easy maintenance of the boiler by following the numeric steps shown in fig. 14. DISASSEMBLY OF EXPANSION VESSEL The heating expansion tank is disas- sembled in the following manner: –... - Page 16 1 Heater stat 2 Cap 3 Heater Fig. 15/b 4.7.1 Cleaning smoke ducts (fig. 16) Use an adequate swab for cleaning the smoke ducts of the boiler. After clean- ing, position the circulators in their original position (fig. 16). RONDO' 3/4 OF ESTELLE 3/4 OF 4.7.2 Cleaning combustion head...
- Page 17 above taking care to respect the of faults which could happen causing obstruction and the cleanness of the indicated measurements. a failure or an irregular function of air duct of the burner (dust). the appliance. A function fault, in most cases, causes the “lock out”...
- Page 18 USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect operation, deactivate it without making any repairs or taking any direct action. If fuel or combustion is smelt, air the room and close the fuel interception device. Contact the authorised technical staff.
- Page 19 the main burner to turn off immedi- ately, whenever the temperature of 110°C is exceeded in the boiler. To restore boiler operation, unscrew the black cap and reset the button (fig. 21). Should the appliance “lock out” again, please approach the author- ised technical staff.
- Page 20 sed technician. CLEANING AND MAINTENANCE At the end of each heating season, it is essential to have the boiler thor- oughly checked and cleaned out. Signal LED Preventive maintenance and check- ing of the efficient operation of the equipment and safety devices must be carried out exclusively by the authorised technical staff.
