6.3.3.4 INFORMATION menu
The INFORMATION menu is read-only and the data cannot be
modified.
From the "Main screen" :
Zone
Menu
– Press the button to view the "Menu" selection
Menu
screen
– Turn the encoder to select the "INFORMATION" menu
GENERAL SETTINGS
INFORMATION
TECHNICAL
Esc
– Press the click encoder to confirm "INFORMATION" and
access the submenu
INFORMATION
Zone heating [...]
Boiler [...]
Heat pump [...]
Hot water [...]
Solar thermal [...]
ˆ
Esc Back
– Turn the encoder to select the required submenu
– Press the encoder to confirm the selected submenu
click
and access the relevant data display
Room temperature
Heating set
Heating temp.
Esc
Thu 18 Set 2014 10:30
Off
Mode
Fig. 122
MENU
[...]
[...]
[...]
Back
Fig. 123
INFORMATION
‡
Alarms [...]
Esc Back
Fig. 124
INFORMATION
20.0°C
80°C
30°C
Back
Fig. 125
– Press the button to go back to the submenus
Back
– Turn the encoder to select another submenu
INFORMATION
Boiler
Heat pump
Hot water
Solar thermal
Firmware version
Esc
– Press the click encoder to confirm the selected submenu
and access the relevant data display
– Continue in this way until all the necessary information has
been shown
– Press the button to go back to the "main screen" .
Esc
Zone
Menu
6.3.3.5 TECHNICAL menu
It is recommended that the TECHNICAL Menu only be used by
professionally qualified technicians, since it is used to modify
system management data.
The submenu "Boiler parameters" requires the CODE (or
password) "1 2 3 4 5" to be entered.
m
CAUTION
We recommend not changing the factory settings so
as not to alter optimal appliance operation. For any
specific support, please contact the Sime Technical
Assistance Service.
From the "Main screen" :
Zone
Menu
[...]
[...]
[...]
[...]
102
Back
Fig. 126
Thu 18 Set 2014 10:30
Off
Mode
Fig. 127
Thu 18 Set 2014 10:30
Off
Mode
Fig. 128
