4.13.1 Using The Buttons - Sime MURELLE REVOLUTION 25 User, Installation And Servicing Instructions

4.13.1 Using the buttons

With the appliance powered, from the "Main screen" .
Zone
Menu
BUTTON (A)
(used mainly by professionally qualified technicians and NOT
by the user)
This allows users to view the "menu" select screen (e.g. Menu
) and then to operate according to what is
"GENERAL SETTINGS"
written above the button on the display (e.g.
and return to the main screen.
GENERAL SETTINGS
INFORMATION
TECHNICAL
Esc
MULTIFUNCTION ENCODER
If turned, allows the user to scroll through and select the
or the "Function mode" , or to change the values in
"Menu/rows"
the selected field.
In "Summer" mode, the DHW temperature can be adjusted.
In "Winter" mode, the DHW can be adjusted in relation to the
heating and the "Holiday function".
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
If pressed, click confirms the selection and takes the user to
the submenus (e.g. "LANGUAGE" or "Hot water" ) or confirms the
modified value or entry.
MENU
GENERAL SETTINGS [...] Language
INFORMATION [...] Date and time
Visualization
TECHNICAL [...]
Factory settings
Esc Back Esc
Thu 18 Set 2014 10:30
Off
Mode
Fig. 40
Esc
MENU
[...]
[...]
[...]
Back
Fig. 41
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
Fig. 42
GENERAL SETTINGS
ENG
Winter
[...] Hot water MAN 40°C
Heating MAN 20.0°C
[...]
[...]
Holiday function OFF
Back Esc Back
Fig. 43
BUTTON (B)
This allows users to view the "Function mode" screen (e.g.
"Winter") and then to operate according to what is written above
the button on the display (e.g.
the main screen).
m
CAUTION
For more information, please see "Commissioning".
to exit
to exit and return to
Esc
Summer Winter Off
Hot water MAN 40°C
Heating MAN 20.0°C
Holiday function OFF
Esc Back
Fig. 44
25
