soundhead oPTIMIzaTIon addIng or rePlaCIng soundheads
Dynatronics Soundhead Sample Parameters Printout
frequency
Impedance
Temperature
NOTE: THE NUMBERS ABOVE ARE PROVIDED FOR ILLUSTRATION ONLY AND SHOULD NOT BE
ENTERED INTO YOUR DYNATRON DEVICE. USE ONLY THE ACTUAL NUMBERS PROVIDED WITH
YOUR OWN SOUNDHEAD.
2. Turn the Solaris Plus Device OFF. Plug in the new soundhead. Turn the Solaris Plus ON.
3. Press the SOUND key followed by the FUNCTION KEY.
NOTE: The Solaris Plus device will automatically recognize the size of the soundhead plugged into the console. To
verify that you are entering the parameters for the correct soundhead, make sure that the HEAD SIZE that appears
on the left-hand side of the Treatment Display Screen is correct. For example, if "5" is displayed, it means the device
senses a 5 cm soundhead is plugged into the console. If correct soundhead size is not visible, use the arrow keys
2
next to the HEAD SIZE display to select the correct soundhead size.
4. As a default, FREQUENCY should appear in the PARAMETER window and 1 MHz in the FREQUENCY window.
Using the Up/Down arrow keys located next to the FREQUENCY display, select the FREQUENCY value for 1 MHz
listed on the Parameter's printout.
NOTE: Parameters must be entered for all three FREQUENCY options 1 MHz, 2 MHz, and 3 MHz shown on the
Parameters printout for Frequency, Impedance, and Temperature.
DYNATRON SOLARIS PLUS SERIES | SERVICE MANUAL REV. 6
®
Serial:
Size (cm):
Cal Date: 9/15/2012
Unit #: Solaris Plus
IHT:
1 MHz
1750
461
8
Manufacture Date: 9/15/2012
5
2 MHz
1950
1064
8
| AUGUST 29, 2017
3 MHz
2050
699
8
