dynaTron solarIs® Plus desCrIPTIons and dIagraMs
Dynatron Solaris
Descriptions and Diagrams
Dynatron Solaris
®
• The Main Board provides routing for communications and power to all boards in the system
• The CPU uses an Analog Devices Blackfin processor and Flash memory to control the resources located on the
various treatment boards and to communication with the User Interface board
• The Light Mezzanine controls the Light Pad and Light Probe
• The STIM 1-2 board connects directly to the Main board and has pass through connections from the Main for the
Ultrasound board and the STIM 3-4 board
• The STIM 1-2 board communicates
and provides output signals to the
STIM 3-4 board
• The SD card interface allows for
field updates of the Operating
software to the CPU
• The Display / Keyboard provides
for the User Interface (cap sense
switches) and drives the liquid
crystal display for user feedback
DYNATRON SOLARIS PLUS SERIES | SERVICE MANUAL REV. 6
®
Plus Description
™
Plus
®
Dynatron Solaris
®
SD Card
Power
Interface
Keypad / Display
Supply
CPU
Light
Mezzanine
| AUGUST 29, 2017
Plus Block Diagram
™
Board
Ultrasound
Main Board
Block Diagram
Board
STIM 1 – 2
Board
STIM
3 – 4
