dynaTron TrI-WaVe™ lIghT ModalITy InforMaTIon
Dynatron Tri-Wave
Modality Information
The Dynatron Tri-Wave™ light probe and Dynatron Tri-Wave™ Light Pad have been cleared by the FDA to provide topical
heating for temporary increase in blood circulation, temporary relief of minor muscle and joint aches, pain and stiffness and
relaxation of muscles; for muscle spasms and minor pain and stiffness associated with arthritis.
Dynatron Tri-Wave
Watt (W) ...........................................................................Energy (1 Joule) delivered per second
Milliwatt (mW) One thousandth of a watt. Power and dose determines length of treatment
Nanometer (nm) .................................................................................... One billionth of a meter.
Joule(s) .........................................................................Watts x seconds = total energy delivered
Dose (per cm
Dynatron Tri-Wave
Following are the General Specifications for the Dynatron Tri-Wave Light Probe and Dynatron Tri-Wave Light Pad. Other
ranges, accuracy and precision values that are not provided here may be obtained from Dynatronics upon request.
The Dynatron Tri-Wave Light Probe is designed with super luminous diodes emitting three different wavelengths of light.
The 20 Infrared SLEDs have a wavelength of 850nm, the 8 Red SLEDs have a wavelength of 624nm and the 6 Blue SLEDs
have a wavelength of 464nm.
DYNATRON SOLARIS PLUS SERIES | SERVICE MANUAL REV. 6
®
Light Basic Vocabulary
™
) ............ J/cm – total energy delivered per square cm in a set period of time.
2 2
Light Probe And Light Pad Specifications
™
Light
™
| AUGUST 29, 2017 70
