eleCTroMagneTIC eMIssIons and IMMunITy
Guidance and Manufacturer's Declaration - Electromagnetic Immunity
The dynatron solaris Plus (and accessories) is intended for use in the electromagnetic environment
specified below. The customer or the user of the Dynatron Solaris Plus (and accessories) should assure
that it is used in such an environment.
emissions Test
electrostatic dis-
charge (esd)
IeC 61000-4-2
electrical fast
transient/burst
IeC 61000-4-4
surge
IeC 61000-4-5
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IeC 61000-4-11
Power frequency
(50/60 hz)
magnetic field
IeC 61000-4-8
noTe: ut is the a.c. mains voltage prior to application of the test level.
DYNATRON SOLARIS PLUS SERIES | SERVICE MANUAL REV. 6
®
IeC 60601
Test level
+/- 6 kV contact
+/- 8 kV air
+/- 2 kV for power
supplyline
+/- 1 kV input/output lines
+/- 1 kV differential mode
+/- 2 kV common mode
<5 % ut
(>95 % dip in ut)
for 0,5 cycle
40 % ut
(60 % dip in ut)
for 5 cycles
70 % ut
(30 % dip in ut)
for 25 cycles
<5 % ut
(>95 % dip in ut)
for 5 seconds
3 a/m
Table 2
Compliance
level
floors should be wood, concrete or
ceramic tile. If floors are covered
Compliant
with synthetic material, the relative
humidity should be at least 30 %.
Mains power quality should be that
Compliant of a typical commercial or hospital
environment.
Mains power quality should be that
Compliant of a typical commercial or hospital
environment.
Mains power quality should be that
of a typical commercial or hospi-
tal environment. If the user of the
equipment requires continued opera-
Compliant
tion during power mains interrup-
tions, it is recommended that the
equipment be powered from an unin-
terruptible power supply or a battery.
Power frequency magnetic fields
not appli- should be at levels characteristic of
cable a typical location in a typical com-
mercial or hospital environment.
| AUGUST 29, 2017
electromagnetic environment
guidance
143
