CoMbInaTIon TheraPy InsTruCTIons
• When using the 708 or 709, since Ultrasound and Stim share the TIME and INTENSITY displays during a
combination treatment, you will need to carefully observe which modality is in focus when setting up or changing
treatment parameters. You may toggle between the Stim and SOUND channel using the CHANNELS toggle key. The
treatment timer does not begin until you press START after both modalities have been set up.

Combination Therapy Setup

1. Press the COMBO key on the 708 and 709. SOUND will be illuminated GREEN in the CHANNELS window and
an automatically selected STIM channel will be illuminated in YELLOW. Other available channels not in use will be
illuminated in WHITE.
2. Plug the combo lead wire into the active STIM channel jack of the 708 or 709. The banana connector end plugs
into the COMBO input jack on the right-side of the unit. The pin end attaches to the dispersive electrode.
3. Apply the dispersive electrode to the patient
4. With SOUND illuminated GREEN, select parameters for the Ultrasound portion of the COMBO treatment
following the instructions found in the manual.
5. Press START.
NOTE: Although parameters and settings are selected for ultrasound therapy, no ultrasound power will be delivered
until you press START after both the ULTRASOUND and STIM modalities have been set up.
6. When using the 708 or 709 press the single-channel STIM option of your choice. The selected STIM channel's illumination
will change from YELLOW to GREEN and become the focus treatment. NOTE: If selecting a Stim channel, other than
the default channel, the illuminated channel will change from WHITE to GREEN. The SOUND channel will now be
illuminated YELLOW. Proceed to set up the STIM treatment following the modality instructions found in the manual.
Remember, Microcurrent must use Channel 1 and High Volt the designated HI-VOLT Channel. The system defaults to
a PREMOD treatment selection unless another default therapy has been selected previously.
7. Apply the conductive gel to the Ultrasound treatment site now. Place the soundhead at the treatment site making
good contact with the skin.
8. Raise the Stim intensity. KEEP THE STIM INTENSITY LOW! If the soundhead is in proper position and coupling
is good, the patient will feel the current. If the patient does not feel the current, check to be sure coupling is good and
make sure you have used ample conductive gel.
