sIMulTaneous TreaTMenTs

Modify Simultaneous Treatments

You may VIEW and MODIFY parameters for the treatment channel(s) that is illuminated GREEN. While two or more
treatments may be in progress at once, the TIME / INTENSITY displays can show only the settings for the focus treatment
whose operational channels are illuminated GREEN. Other channels in use at that time will be illuminated YELLOW
indicating that the channels are active (delivering current) but their parameters are not currently displayed or in focus.
All channels that are currently operational but not in focus, are listed both in the CHANNELS window and in small font on
the left-hand side of the Treatment Display Screen under the heading, RUNNING TREATMENTS. Included in the list under
RUNNING TREATMENTS, is the active channel(s) illuminated in YELLOW; and the name of the treatment modality with
the remaining treatment time, both illuminated in White.
To change the settings for a channel or output that has a YELLOW light, press the CHANNELS toggle key one or more times
until the light for the desired channel becomes GREEN. The TIME and INTENSITY displays change to show the parameters
currently in effect for that treatment. Once a treatment is in focus, the parameters may be changed.
