dynaTron® TherMosTIM™ Probe
Dynatron
ThermoStim
An accessory to the Solaris Plus, the ThermoStim Probe provides cold, heat, and electrical stimulation all in one tool.
The multi-surface head with edges and corners optimizes ThermoStim transfer and tissue mobilization. With the ability to
deliver three separate treatments simultaneously, the ThermoStim Probe saves significant treatment time.
Functionality
The ThermoStim Probe is designed to operate in conjunction with six separate Stim modalities: Premod, Interferential,
Biphasic, Russian, Microcurrent, and High Volt.
During a Stim treatment, the probe takes the place of one of the electrodes. Stim current passes between the probe and the
patient electrode while combined with heat or cold introduced into the patient's tissue through the probe.
For example, with a normal bipolar (2 electrodes) Stim treatment, one electrode would be placed on the patient (this electrode
should be twice the size of the treatment probe, minimal 2" x 4") and the ThermoStim probe would be used as the second
electrode to complete the set-up. A specially designed patient lead wire is included with the Dynatron ThermoStim probe.
Heat or cold may be used separately without Stim as well.
• Avoid touching the patient electrode with the probe during a treatment.
• A conductive gel should be applied to the patient's skin where the ThermoStim probe is to be applied to ensure
ample conductance during the Stim treatment
• Maintain at least 50% of the probe face in contact with the patient at all times
