Event Lighting M1B60W User Manual page 6

Brand Show①
Key Lock①
Language①
Users User Mode①
Edit User③
Calibration③ -Password-
Color
:
Fixture ID③ Name
-Password-
PID Code
Wireless Set① DMX On Cable
Reset Connect
Reload Default Basic Reload(①)
Program Reload(②)
---Password---
Private Reload(③)
All Reload
Play① DMX Receive
Slave Receive
Sequence
Music
Select Chase② Chase Part 1
Chase Part 2
Chase Part 3
Edit Chase② Chase 1
:
:
Chase 8
Edit Scenes② Edit Scene 001
~ Edit Scene 250
Scenes Record ScXX=>ScXX
6
ON/OFF
ON/OFF
En/简/繁/Fr/Sp
Standard
Extended
Basic-8bit
Basic-16bit
User
Max Channel = XX
PAN = CH01
:
=XXX
=XXX
:
ON/OFF
ON/OFF
ON/OFF
ON/OFF
XXX
ON/OFF
ON/OFF
Slave Receive 1,2,3
Master / Alone
Master / Alone
Chase 1 ~ 8 Chase 1
Chase 1 ~ 8 Chase 2
Chase 1 ~ 8 Chase 3
Chase Test
Step 01 =SCxxx
: :
Step 64 =SCxxx
Pan,Tilt,...... =xxx
Fade Time-- =xxx
Secne Time-- =xxx
DMX Input
Show brand or not
Key lock on/off
Language Select
Standard mode
Extended mode
Basic mode-8bit
Basic mode-16bit
User program mode
Edit users mode
Password: 050
Calibrate channel value
Name
Password: 050
Set PID of RDM
DMX Send Out
Reset Connect
Basic Reload
Program Reload
Password: 050
Private Reload
All Reload
DMX Receive
Choose slave position
Run Sequence
Music mode
Select and run auto
program
Test
Beginning scene
:
Ending scene
Input manual scene
Modify manually fading time
Modify manually scene time
Input scene from exterior
controller
Auto Input scenes
