More functions
RDM. RDM stands for "Remote Device Management", with this function, users can realize remote control of the
-
device, such as remotely changing DMX address, reverse pan/tilt setting, check a lot of useful information such as
temperature, power consumption, fan speed. Etc. Every single device has a unique RDM code programmed at
manufacture to distinguish from each other. It is not recommended for users to change this code.
- Software upgrade function via DMX cable. If there is any new firmware for this device, it can be upgraded simply via
a software upgrade box, no need to change any mechanical parts. The upgrade box is not included in the package,
if need any further assistance please just contact your authorized dealer.
- Hibernation. The device will enter sleeping mode if activated after a period of disconnecting DMX signal to save the
power consumption, and will return immediately as soon as the DMX signal is sent again.
- Display back-up communication IC. There is a back-up communication IC installed in the display PCB, so users
could replace at once if the original one is broken.
- Display flip. By press up and down button for more than 3 seconds, the display will flip automatically, this function is
useful to read menu conveniently when device is hanged.

Technical Specifications

- Input Voltages: 100V~240V AC, 50/60Hz
- Power Consumption: 145W
- Light source:CBT-90 60W white LED module
- Power Connection: Neutrik® Powercon input and output connection
- LED life: 60,000 hours
- Lux: 6,500 lumen, 11,540 lux on @5M
- Beam angle: 5°
- PWM: 1,200Hz
- Colors: 1 color wheel with 8 colors + open
- Gobos: 1pc 11 + open fixed gobo wheel
- Effect: 3 facets, 8 facets prism, frost
- Dimmer: 0-100% dimmer
- Strobe: 0.5 - 26 Hz
- Focus: linearly focusing controlled by DMX
- Head movement: Pan: 630°(4.0 sec)or 540°(3.58 sec), Tile 265°(2.8 sec).16-bit resolution, auto repositioning
- Control: DMX512, 3-pin XLR interfaces, 21/24/14/16 channel mode
- Other function: wireless DMX is available
- 2.4 inch colour LCD display with back-up power.
- Thermostat Controlled, variable speed fan
- RDM and software upgrade via DMX.
- Net weight: 11.5Kg
- Overall Size: 343x319x513mm
Rigging: 1pc omega brackets with 1/4 – turn quick locks
-
- Road case available
