14 Connecting the reflow controller to the reflow oven and PC
The reflow controller (A) is connected via a sensor (C) to the reflow oven (B) and option-
ally via a USB cable (D) to a PC (E). Mains power is supplied via a power cable (F). The
oven is connected using an adapter cable (G).
B
G
C
A
D
Reflow Controller V3 PRO
Operating Instructions
F
A
Reflow controller
B
Reflow oven
C
Sensor
D
Optional USB cable
PC (optional)
E
Power cable
F
Adapter cable
G
E
Page 39 of 39
