9. 7 Commands for parameter setting and calibration

The reflow controller can be set for different solder pastes, different temperature sensors
and different oven types. The parameters necessary to make those settings are input
via the computer interface.
Please ensure that all settings relate to the parameter set currently in use. You can store
up to 5 different settings (parameter sets) in the controller. In the case of all commands,
if the command has no parameters, the controller will display the value currently set.
Command
phttemp
phttime
phtpwr
soaktemp
soaktime
soakpwr
Parameter Definition
[0 .. 254] °C End temperature of the preheat phase
[32 .. 490] F
phttemp 125<ENTER>
sets the temperature to 125 °C.
[0 .. 65534] Sek. Duration of the preheat phase
If the parameter is set to 0, the controller itself
will define the duration of the "Preheat" phase.
The oven will be operated at the set capacity until
the preset temperature has been reached.
phttime 180<ENTER>
sets the duration to 180 seconds.
[0 .. 100] % Heat capacity of the preheat phase
phtpwr 60<ENTER>
Oven will operate at 60 % heat capacity.
[0 .. 254] °C End temperature of the activation or soak phase
[32 .. 490] F
soaktemp 175<ENTER>
sets the temperature to 175 °C.
[0 .. 65534] Sek. Duration of the activation phase
If the parameter is set to 0, the controller itself
will define the duration of the "Soak" phase.
The oven will be operated at the set capacity until
the preset temperature has been reached.
soaktime 90<ENTER> sets the duration to
90 seconds.
[0 .. 100] % Heat capacity of the activation phase
soakpwr 80<ENTER>
Oven will operate at 80 % heat capacity.
Reflow Controller V3 PRO
Operating Instructions
Page 30 of 39
