The "Pulse" phase will appear in the last line of the display. In "Manual" mode, it is not
possible to use the keyboard or carry out normal soldering functions.
Manual 75F
Puls
When a heat pulse is now released via the interface, the pulse capacity is displayed
simultaneously for exactly one second; so for example, a 50% pulse would be displayed
as follows:
Manual 75F
Puls 50%
In "Manual" mode, you can release single heat pulses via the serial interface using the
command "shot X", where X indicates the required capacity in %.
A heat pulse always lasts for a second. You can use the parameter "Capacity" to deter-
mine for how long the heat is actually switched on during a heat impulse.
Example:
shot 10 --> 10 % capacity for 1 second --> Heating is on for 100 ms and off for 900 ms
shot 25 --> 25 % capacity for 1 second --> Heating is on for 250 ms and off for 750 ms
At the end of a heat pulse, the measured temperature is displayed via the interface in
the format "shot, seconds, +xxx, unit".
Example:
shot, 31, +058, C bzw.
shot, 31, +136, F
A period of 31 seconds has elapsed since the controller was switched on and the tem-
perature measured was 58 °C. Data elements are separated by a comma, which makes
it easier to separate each value in the control program.
Please note that for safety reasons, the oven cannot be switched on permanently via the
interface. Every heat pulse takes exactly a second. If the connection to the control compu-
ter is lost, the oven will switch off in a second at most.
The "Shot" command can only be used under the following circumstances:
• The controller is in "Manual" operating mode.
• A previous heat pulse is completed.
