Base Values
Autoextend
• Pressing OK will activate the menu item and the text showing the current setting will
start to flash.
• The UP and DOWN buttons can be used to change the value as required.
• Press OK to confirm.
8.5.2 Temperature calibration
The temperature sensor for the reflow controller is preset and generally does not need
to be calibrated. However, if required, the reflow controller can be synchronised with the
sensor.
You can set temperature calibration as follows:
• Go to the "Base values" menu (see chapter "Base values").
• Select the menu item "TempOffset". The display shows the current setting of this
value in the selected temperature unit.
Base Values
TempOffset
• Pressing OK will activate the menu item and the value to be adjusted will start to flash.
• The UP and DOWN buttons can be used to change the value as required.
Press OK to confirm.
User diagram for sections 8.5.1 "Automatic phase extension" and
8.5.2 "Temperature calibration"
OFF
10F
Reflow Controller V3 PRO
Operating Instructions
Page 22 of 39
