• Then select the next parameter using the LEFT or RIGHT button and make the change.
• When you have set all the "Soak" parameters, you can end parameter input by pres-
sing OK.
Please note that pressing OK always ends parameter input, even if not all parameters
have yet been changed. You are now back in the "Settings" menu.
8.4.5 Reflow
This menu item allows you to change the parameters for the "Reflow" phase.
The parameters are as follows:
• Duration of the phase in seconds
• Required end temperature of the phase in the specified temperature unit
• Oven performance during the phase in %
Please note that the settings always affect the currently active parameter set. Informati-
on on switching the active parameter set can be found in the chapter "Profiles".
You can set the "Reflow" parameters as follows:
• Select the menu item "Reflow" in the "Settings" menu.
The chapter 'Settings' contains further details. In the menu item "Reflow", the number
of the active parameter set is also displayed in the first line.
Setup
Reflow
• Pressing OK will activate the menu item. You will now see the name of the activated
menu item (Reflow) and the number of the current parameter set on the display. The se-
cond line shows the name of the selected parameter to be changed and its current value,
which will flash onscreen. This means that the value can be changed using UP/DOWN.
Reflow
power:
• Set parameters.
• Then select the next parameter using the LEFT or RIGHT button and make the change.
• When you have set all the "Reflow" parameters, you can end parameter input by pres-
sing OK.
Please note that pressing OK always ends parameter input, even if not all parameters
have yet been changed. You are now back in the "Settings" menu.
2
2
080%
