Beta Layout Reflow-Kit V3 PRO Operating Instructions Manual page 31

Command Parameter
reflowtemp
[0 .. 254] °C
[32 .. 490] F
reflowtime [0 .. 65534] Sek. Duration of the reflow phase
reflowpwr
[0 .. 100] %
dwelltemp [0 .. 254] °C
[32 .. 490] F
dwelltime
[0 .. 65534] Sek. Duration of the "Dwell" phase
dwellpwr [0 .. 100] %
tempoffset [-30 .. 30] °C
[-54 .. 54] F
Definition
End temperature of the reflow phase
reflowtemp 232<ENTER>
sets the temperature to 232 °C.
If the parameter is set to 0, the controller itself will
define the duration of the reflow phase.
The oven will be operated at the set capacity until
the preset temperature has been reached.
reflowtime 140<ENTER>
sets the duration to 140 seconds.
Heat capacity of the reflow phase
reflowpwr 100<ENTER>
Oven will operate at 100 % heat capacity.
End temperature of the "Dwell" phase
dwelltemp 232<ENTER>
sets the temperature to 232 °C.
If the parameter is set to 0, the controller itself
defines the duration of the "Dwell" phase.
The oven will be operated at the set capacity until
the preset temperature has been reached.
dwelltime 40<ENTER>
sets the duration to 40 seconds.
Heat capacity of the "Dwell" phase
dwellpwr 80<ENTER>
Oven will operate at 80 % heat capacity.
Adjusting the temperature sensor
This setting is universal and applies to all parame-
ter sets.
tempoffset -3<ENTER>
3 °C is deducted from the measured temperature.
The temperature less 3 °C is displayed.
tempoffset 5<ENTER>
5 °C is added to the measured temperature.
The temperature plus 5 °C is displayed.
Bedienungsanleitung
Reflow-Controller
Page 31 of 39
