Command Parameter
autoextend
[0 .. 1]
mta [0 ... 65534]

9.8 Manual operation

The operating mode "Manual operation" can only be controlled via the PC.
In effect, this operating mode allows you full access to the controller, which means you
can write your own controller programs on the PC.
You can also devise special profiles or applications, for example, "managed cooling" of
sintered tools.
When the controller is in "Manual" mode, the message "Manual" will be shown in the
display line, along with the current temperature.
Definition
Controlling automatic soldering phase extension
autoextend 1<enter>
Switch on automatic soldering phase extension.
If the preselected end temperature for this phase
has not been reached in the set time, the phase
will be extended until the set temperature has
been reached.
autoextend 0<enter>
Switch off automatic soldering phase extension.
When the set phase duration is complete, the next
phase will start regardless of whether the preset
temperature for the phase was reached.
This parameter is universal and applies to all solder
curves.
Controlling oven monitoring
mta 0<enter>
Switch off automatic oven monitoring.
mta X<enter>
X>0 Switch on automatic oven monitoring.
This command checks that the oven temperature
has reached a level of at least X * 0.25 °C within
15 seconds. If this is not the case (e.g., due to a
defective oven or the oven door not being closed
fully), the soldering process is terminated and an
error message displayed.
Reflow Controller V3 PRO
Operating Instructions
Page 32 of 39
