8.2 Menu layout

The controller has three different menus.
Main menu
When the controller is switched on, you are in the main menu. From the main menu, you
can start a soldering process or a learn cycle.
Settings
You can go to the "Settings" menu by switching the controller to parameterisation mode
(see previous chapter). In this menu, you can make all the parameter changes necessary
for your soldering process.
Base values
You can get to the "Base values" menu via the "Settings" menu. In the "Base values"
menu, you can adapt controller performance to your own requirements. Aside from the
initial setup, no changes are usually required in this menu.
8.3 Main menu
The main menu contains the following menu items:
Ready "Normal" controller operation.
Pressing START will initiate a soldering cycle.
Setup
Entry point to the "Settings" menu. See chapter "Switching the controller to
parameterisation model" for further information.
Learn
Initiates a learn cycle. Press START to begin a cycle. See chapter "Learning
the oven characteristics" for further information on the learn procedure and
how to use it.
8.4 "Settings" menu
You are in the "Settings" menu when the status "Setup" appears in the first line of the
display and the current menu item is on the second line.
Setup
Preheat
The "Settings" menu contains the following menu items:
Ready
Profile
Menu exit point. Press OK to return to the main menu.
Active parameter set selection
