8.4.2 Using the parameters

Entry Parameter
When you have set all the parameters as required, press OK to confirm the settings.
Please note that pressing OK always ends parameter input, even if not all parameters have yet been
changed. You are now back in the "Settings" menu.
8.4.3 Preheat
This menu item allows you to change the parameters for the "Preheat" phase. The para-
meters are as follows:
• Duration of the phase in seconds
• Required end temperature of the phase in the specified temperature unit
• Oven capacity during the phase in %
Please note that the settings always affect the currently active parameter set. Informati-
on on switching the active parameter set can be found in the chapter "Profiles".
You can set the 'Preheat' parameters as follows:
• Select the menu item "Preheat" in the "Settings" menu.
The chapter "Settings" contains further details. In the menu item "Preheat", the num-
ber of the active parameter set is also displayed in the first line.
Setup
Preheat
• Pressing OK will activate the menu item. You will now see the name of the activated
menu item (Preheat) and the number of the current parameter set on the display. The
second line shows the name of the selected parameter to be changed and its current
value, which will flash onscreen.
This means that the value can be changed using UP/DOWN.
Select next
parameter
4
Set parameter Select next
parameter
Reflow Controller V3 PRO
Operating Instructions
Exit
