the menu item "Base values" in the "Settings" menu (see chapter "Settings"). You are in
the "Base values" menu when you can see the status "Base values" in the first line of
the display and the current menu item in the second line.
Base Values
Ready
The "Base values" menu contains the following menu items:
Ready
Autoextend
TempOffset
TempUnit
Factory Default Resets all values to default
You can use UP or DOWN to navigate to the last or next menu item, respectively. If
you want to change the settings in a menu item, scroll to the item using UP/DOWN,
then press OK.

8.5.1 Automatic phase extension

Automatic phase extension involves extending a soldering phase beyond the set phase
duration if the target temperature was not reached in the set time.
This is necessary if, for example, you are not familiar with the heat performance of the
oven and first want to test how long it takes for the oven to reach the target tempera-
ture using the specified performance settings. You can switch the "Autoextend" function
on or off.
Autoextend ON:
This allows a soldering phase to be extended until the oven is heated to the set end
temperature for that phase. If the end temperature is reached within the given time, the
phase is not extended.
AutoExtend OFF:
When the set phase duration is complete, the next phase starts regardless of whether
the phase end temperature was reached.
You can change the "Autoextend" function as follows:
• Go the "Base values" menu (see chapter "Base values").
• Select the menu item "Autoextend". The current setting is shown in the display.
Menu exit point. Press OK to return to the main menu.
Automatic phase extension On/Off
Temperature calibration/Sensor error adjustment
Temperature unit settings °C / °F
