Chapter 1

Adjust The Scanning Beam

NOTE: Make sure the printer is on and the scanning beam is on. If

When the validator is first installed, the scanning beam may need to

be aligned with the two notches on the sides of the tear bar, as

shown in Detail A of Figure 12. When the scanning beam is

properly aligned it will line up with the two notches.

Figure 12. Aligning the Scanning Beam

the beam is off, press the RESET button for less than 2

seconds to turn on the beam.

Scanning Beam

Notch in Tear Bar

t 5 l s r l c 2

J u n e 1 9 , 2 0 0 0
