Printronix T5000e Series Module Manual page 24

Chapter 1
Installation
Validator
(Rear View)
Bracket
Validator
(Front View)
Figure 10. Installing the Validator/Upper Bracket Unit onto the Lower Bracket
2. Face the front of the printer while installing the validator/upper
3. Loosen the two adjustment screws on the bottom of the
4. Slide the validator/upper bracket unit onto the lower bracket and
NOTE: The printer model size is also inscribed on the lower
5. When the unit is positioned correctly, tighten the two
24
Hash
Marks
Lower
Bracket
Upper
Adjustment
Screw (2)
bracket unit.
validator.
align the hash marks accordingly. Refer to Figure 10, Detail A for
location of the validator hash mark for each printer model size.
bracket.
adjustment screws on the validator to lock the unit into place.
A
4 in. 6 in. 8 in.
Printer
A
