1
PANEL DESCRIPTION
Programmable function keys (Continued)
• For [R], [P0], [P1], [P2], [P3], [UP] and [DOWN]
The key names that are in quotation marks in the fol-
lowing explanations are displayed on the Function Dis-
play, and indicate the assigned function of [P0], [P1],
[P2] and [P3].
None
No function
Autodial "ADAL" (p. 3-2)
Opens the DTMF Autodial code selection screen.
Autodial Programming "ADPG" (p. 3-3)
Enters the DTMF code programming mode.
AUX A "AUXA"
Turns the AUX A port ON or OFF.
AUX B "AUXB"
Turns the AUX B port ON or OFF.
Broadcast "BCST"
Toggles between Broadcast Call and Conference Call.
This key can also be used to make a Broadcast Group
Call.
Call 1 "CAL1"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 1.
Call 2 "CAL2"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 2.
Call 3 "CAL3"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 3.
Call 4 "CAL4"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 4.
Call 5 "CAL5"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 5.
Call 6 "CAL6"
Sends the NXDN Status, NXDN Individual or the DTMF
code that is set to Call 6.
CH/GID Down "CH D"
Selects the next or previous channel or GID number.
CH/GID Recall "CHRC"
❍ In the Analog mode or
NXDN Conventional system
Selects the last used channel during a scan.
❍ In the NXDN Trunking system
Selects the last called GID during a scan.
CH/GID Up "CH U"
Selects the next or previous channel or GID number.
Channel Entry "CHEN" (p. 2-4)
Enters the Channel Entry mode.
CW Message "CWMS"
Sends a preset CW Message on a 'very narrow' chan-
nel.
You can use this function when a CW message is pre-
set.
Direct CH/GID 1 "DR 1" (pp. 2-4, 7-3)
Selects the channel or GID that is set to Direct CH/
GID 1.
Direct CH/GID 2 "DR 2" (pp. 2-4, 7-3)
Selects the channel or GID that is set to the Direct CH/
GID 2.
Direct CH/GID 3 "DR 3" (pp. 2-4, 7-3)
Selects the channel or GID that is set to Direct CH/
GID 3.
Direct CH/GID 4 "DR 4" (pp. 2-4, 7-3)
Selects the channel or GID that is set to Direct CH/
GID 4.
Direct CH/GID 5 "DR 5" (pp. 2-4, 7-3)
Selects the channel or GID that is set to Direct CH/
GID 5.
Direct CH/GID 1 Select
This function is for the hold down operation of [Direct
CH/GID 1].
Sets the selected channel or GID to Direct CH/GID 1.
1-5
