INSTRUCTION MANUAL
VHF MOBILE TRANSCEIVER
iF5122D
UHF MOBILE TRANSCEIVER
iF6122D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F5122D and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-F5122D

Summary of Contents for Icom IC-F5122D

  • Page 1 INSTRUCTION MANUAL VHF MOBILE TRANSCEIVER iF5122D UHF MOBILE TRANSCEIVER iF6122D...

  • Page 2: Explicit Definitions

    F6122D UHF MOBILE TRANSCEIVER. of personal injury, fire or electric shock. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United King- dom, Germany, France, Spain, Russia and/or other countries.

  • Page 3: Precautions

    PRECAUTIONS R WARNING! NEVER DO NOT connect the transceiver to an use or place the transceiver in areas with tem- AC outlet. This may pose a fire hazard or result in an electric peratures below –25°C or above +55°C, or in areas subject shock.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ................i 3 CONNECTION AND MAINTENANCE ....15–17 EXPLICIT DEFINITIONS ............i ■ Rear panel connection ..........15 PRECAUTIONS ..............ii ■ Supplied Accessories ..........16 TABLE OF CONTENTS ............iii ■ Mounting the transceiver ..........16 ■ Antenna ..............17 ■...

  • Page 5: Panel Description

    PANEL DESCRIPTION ■ Front panel Function display (p. 2) Speaker q AF VOLUME CONTROL KNOB [VOL] t MICROPHONE CONNECTOR Rotate the knob to adjust the audio output level. Connect the supplied or optional microphone. • Minimum audio level is pre-programmed. (p. 12) NEVER connect non-specified microphones.

  • Page 6: Function Display

    PANEL DESCRIPTION ■ Function display y ENCRYPTION ICON Appears when the encryption function is activated while operating in the digital mode. u BELL ICON Appears/blinks when a matching 2/5-tone or Digital ID* is received, depending on the preprogramming. i SCAN ICON ➥...

  • Page 7: Programmable Function Keys

    [P0], [P1], [P2] and [P3] programmable function keys. • When a scan is started with the Power ON Scan or Automatic Consult your Icom dealer or system operator for details con- scan function, push this key to cancel it. The cancelled scan cerning your transceivers programming.
  • Page 8 PANEL DESCRIPTION ■ Programmable function keys (Continued) LOCK KEY PRIO A/B KEYS ➥ Hold down this key until “LOCK ON” is displayed to elec- ➥ Push to select the Priority A or Priority B channel. tronically lock all programmable keys except the follow- ➥...
  • Page 9 PANEL DESCRIPTION TONE/RAN CH SELECT KEY WIDE/NARROW KEY ➥ While in analog mode, push to enter the continuous tone Push to toggle the IF bandwidth between wide and narrow. channel selection mode. Then push [CH Up] or [CH Down] • The wide passband width can be selected from 25.0 or 20.0 kHz using the CS-F3100D/F5120D .
  • Page 10 PANEL DESCRIPTION ■ Programmable function keys (Continued) TX CODE CHANNEL SELECT KEY CALL KEYS ➥ Push to enter the TX code channel selection mode, then Push to transmit a 2/5-tone ID code. push [CH Up] or [CH Down] to set a desired channel. •...

  • Page 11: Panel Description

    PANEL DESCRIPTION USER SET MODE KEY Ext. CH Sel Mode KEY ➥ Hold down for 1 second to enter the User Set mode. Push to turn the Ext. CH Select function ON or OFF. • While in the User Set mode, push this key to select an item*, When the function is turned ON, memory channels can be and change the value or setting using [CH Up] or [CH Down].

  • Page 12: Basic Operation

    BASIC OPERATION ■ Turning ON the power ■ Channel selection q Push [ ] to turn ON the power. There are several methods to select channels, and they may w If the transceiver is programmed for a start up password, differ, depending on your system set up.

  • Page 13: Call Procedure

    BASIC OPERATION ■ Call procedure ■ Receiving and transmitting Receiving: When your system employs tone signaling (excluding CTCSS and DTCS), a call procedure may be necessary prior to voice q Hold down [ ] for 1 second to turn ON the power. transmission.

  • Page 14: D Tx Code Channel Selection

    BASIC OPERATION ■ Receiving and transmitting (Continued) D TX code channel selection D Transmitting notes If the transceiver has a key assigned to [TX Code CH Select], • Transmit inhibit function the dysplay can be toggled between the operating channel The transceiver has several inhibit functions which restrict number (or name) and TX code channel number (or name).

  • Page 15: D Dtmf Transmission

    BASIC OPERATION D TX code number edit (PMR operation only) USING [TX CODE ENTER] KEY: If the transceiver has a key assigned to [TX Code CH Select] q Push [TX Code Enter] to enter the TX code edit mode. or [TX Code Enter], TX code contents can be edited within the allowable digits.

  • Page 16: User Set Mode

    BASIC OPERATION ■ User Set mode r Push [P0] several times to select the appropriate item, The User Set mode can be accessed with the ‘Power ON’ then push [Up] or [Down] to set the desired level or set- function. In this case, all set mode items are selectable. ting.

  • Page 17: Encryption Function

    BASIC OPERATION ■ Emergency transmission D NOTES When [Emergency] is held down for the specified time pe- Depending on the preprogramming, the following functions riod*, the emergency signal is transmitted on the specified are automatically activated. Ask your dealer for details. emergency channel once or repeatedly.

  • Page 18: Stun Function

    BASIC OPERATION ■ Stun function To activate the Power OFF Emergency function, turn the power OFF while holding down [Power OFF Emergency]. When the function is activated, any key operation, the ON/ The dispatcher can send a 2/5-tone signal that will stun, kill OFF Hook and Lone Worker functions become invalid.

  • Page 19: Connection And Maintenance

    CONNECTION AND MAINTENANCE ■ Rear panel connection q ANTENNA CONNECTOR e MICROPHONE HANGER Antenna Connect to an antenna. Ask your Connect the supplied micro- phone hanger to the vehicle’s dealer about antenna selection and placement. ground for microphone ON/OFF hook functions. (See page 1) w EXTERNAL SPEAKER JACK Connect to a 4 to 8 ø...

  • Page 20: Supplied Accessories

    CONNECTION AND MAINTENANCE ■ Supplied Accessories ■ Mounting the transceiver The universal mounting bracket supplied with your trans- Microphone Microphone hanger Microphone ceiver allows overhead mounting. and screw set hanger cable • Mount the transceiver securely with the four supplied screws to a thick surface which can support more than 1.5 kg.

  • Page 21: Antenna

    Icom transceiver. DO NOT use harsh solvents such as benzine or Icom is not responsible for the destruction or damage to an Icom transceiver in the event the Icom transceiver is used with equipment alcohol, as they will damage the transceiver sur- faces.

  • Page 22: Country Code List

    Romania France Slovakia Germany Slovenia Greece Spain Hungary Sweden Iceland Switzerland Ireland Turkey Italy United Kingdom Latvia About e-marking: Detailed installation notes for Icom mobile transceivers to be fitted into vehicles are available. Please contact your Icom dealer or distributor.
  • Page 23 MEMO...
  • Page 24 < Intended Country of Use > A-6906H-1EU-qa Printed in Japan © 2011 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
  • Page 25 EN 301 489-5 V1.3.1 (2002-08) vii) EN 60950-1:2006/A1:2010 MAY.2011 Versions of the IC-F5122D which display the “CE” symbol on the serial number label, comply with the essential requirements of the European Radio and Telecommunication Terminal Directive 1999/5/EC. This warning symbol indicates that this equipment...
  • Page 26 ABOUT CE DECLARATION OF CONFORMITY We Icom Inc. Japan 1-1-32, Kamiminami, Hirano-ku Osaka 547-0003, Japan Declare on our sole responsibility that this equipment complies with the essential requirements of the Radio and Telecommunications Terminal Bad Soden 11th Jul. 2011 Equipment Directive, 1999/5/EC, and that any applicable Essential Test Place and date of issue Suite measurements have been performed.
