7
NXDN OPERATION <TRUNKING MODE>
Transmitting a call (Continued)
D Short Data call
You can send a Short Data message of up to 100 char-
acters.
If you turn OFF the transceiver's power, the message
is cleared.
Push [SDM (NXDN)] to enter the Short Data Mes-
q
sage Entry mode.
• Displays "MESSAGE?".
MESSAGE?
Push [UP] or [DOWN] to enter a character, and then
w
push [P1](SET) to set.
• Goes to the next character entry position.
• You can use the 10-keypad keys on the microphone.
Repeat step w until you enter a message of up to
e
100 characters.
• Push [P0](DEL) to delete a character.
• Push [P2](Ω) or [P3](≈) left or right to select a charac-
ter.
SHORT MESSAG
Push [PTT] to send.
e
• Displays "SEND DATA" and then "COMPLETE."
Push [P1](EXIT) to exit.
r
If you exit from the Short Data Message Entry mode,
and then you want to send the message again, do the
following steps.
Push [SDM (NXDN)] to enter the Short Data Mes-
q
sage Entry mode.
• Displays the entered message.
• Displays the last part of the message if the message is
over 12 characters.
HORT MESSAGE
Push [PTT] to send.
w
• Displays "SEND DATA" and then "COMPLETE."
Push [P1](EXIT) to exit.
e
D Long Data call
You can send a Long Data message of up to 4,096
characters only by using an external device, such as a
PC. You cannot send a Long Data message by pushing
[PTT].
7-8
