Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Key-type vehicles
Wait until the LED turns ON solid red.
1
Notes: To skip the transponder programming and use convenience features only,
press the programming button 5 times. When the LED turns ON solid orange,
proceed to step 2.
Turn the ignition ON. The LED flashes orange quickly for approximately 5 seconds,
then flashes green. It may flash green for 25 seconds.
Note: If the LED flashes red 3 or 4 times after the initial 25 seconds, wait an extra 30
2
seconds.
If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF once the module is successfully programmed without
transponder.
When the LED starts flashing orange slowly, turn the ignition OFF, remove the
module from the vehicle and reconnect it to your computer. The web site will
3
automatically recognize that you are moving onto the second phase of the
programming sequence.
4
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid
5
green for 3 seconds, then turns OFF.
6
Turn the ignition OFF and remove the key from the ignition barrel.
You have successfully completed the module programming sequence.
Push-to-Start (PTS) vehicles
Wait until the LED turns ON solid red.
1
Notes: To skip the transponder programming and use convenience features only,
press the programming button 5 times. When the LED turns ON solid orange,
proceed to step 2.
Press on the Push-to-Start (PTS) button twice to turn the ignition ON. The LED flashes
orange quickly for approximately 5 seconds, then flashes green. It may flash green for
25 seconds.
Note: If the LED flashes red 3 or 4 times after the initial 25 seconds, wait an extra 30
2
seconds.
If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF once the module is successfully programmed without
transponder.
If the LED starts flashing orange slowly, turn the ignition OFF, remove the module
3
from the vehicle and reconnect it to your computer. The web site will automatically
10
