Wiring Diagram - Directechs DB3 Installation Manual

Wiring diagram

Important!
- The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL.
- Refer to the Wiring Reference Chart section for more information on specific wiring and connections.
(under drivers dash)
Immo.
Data:
Red,
pin 35
35
6
(+) Starter: Yellow, pin 6
Immo.
[2]
Ignition:
Pink, pin 2
Immo. Ignition Interrupt (vehicle side): Yellow/Orange: 9
[2]
Not required in D2D mode.
6
BCM
11
27
B-CAN High:
Pink, pin 20
20
21
(+) Ignition:
Gray, pin 32
2 9
32
(-) PTS:
[3]
Black, pin 9
HS CAN High: Tan/Black: 3
Cut
HS CAN Low: Tan: 4
FT CAN High: Orange/Green: 5
FT CAN Low: Orange/Brown: 6
Imm. Ignition Interrupt (conn. side): Yellow: 8
[2]
(+) 12V (+) 12V: Red: 13
(-) Ground (-) Ground: Black: 14
(-) E-brake Status: Black/White: 1
(-) Door/Trunk Status: Green/White: 3
(-) PTS Output: Red/Black: 4
[3]
(AC) Tach Output: Violet/White: 5
[1]
(+) Brake Status: Gray: 6
Immobilizer Data: Yellow/Black: 10
(-) Hood Status: Blue: 12
(-) Hood Input
(+) Brake Input
(AC) Tach Input
[1]
(-) Door Status Input
(-) E-Brake Input
(-) Parking Light Output
(+) 12V
(+) Ignition Input/Output
(+) Starter Output
(-) Ground
(-) Parking
Lights:
Gray,
pin 11
(+) 12V:
Red, pin 27
B-CAN
Low:
Blue,
pin 21
(-) Lock Output
(-) Unlock Output
(-) Trunk Release Output
(-) GWR (Status)
OBDII Diagnostic
Connector
F-CAN High: White, pin 6
1 8
9
16
F-CAN Low: Red, pin 14
(+)12V
RX
(-) Ground
P#: XKD2D65
TX
10: Blue/White: (-) GWR Input
9 Pink: (+) Ignition Input :
8 Violet: (+) Start : Input
3: Red/White: (-) Trunk Input
2: Blue: (-) Unlock Input
1: Green: (-) Lock Input
403.HONDA7 2.19 2016 Honda Civic (Smart Key)
© 2016-11-17 Directed. All rights reserved.
