Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Ensure vehicle is in a safe location and cannot move forward during programming. For
1
vehicles equipped with a manual transmission, make sure the gearshift is in the neutral
position.
The harnesses must be connected in this exact order:
a) Connect the 14-pin.
2
b) Connect the 12-pin.
c) Connect the 10-pin.
When the LED turns on solid red, proceed with the next step.
Press the PTS button twice (2) to turn the ignition ON.
3
The LED will flash green quickly.
4
Wait for the LED will turn on solid green for 3 seconds and then turn off.
Press the PTS button once (1) more to turn the ignition OFF.
5
Note: Vehicle must be locked and armed for at least 45 seconds before remote starting.
See "Pre-installation and application warnings" for additional information.
You have successfully completed the module programming sequence.
10
403.HKRS03 1.03 2021 Kia K5 2.5L Turbo (Smart Key)
