Vehicle connections

The connection information listed below is specific to the 2016 Honda Civic (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange or Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
7
Description
(DATA)
(DATA)
(DATA) HS CAN High
(DATA) HS CAN Low
(DATA) FT CAN High
(DATA) FT CAN Low
Relay N.O.
Relay COM Ignition Output
Relay N.C. Ignition Input
Relay N.C.
Relay COM
Relay N.O.
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) W2W Only - E-Brake Output
(-)
(-) W2W Only - Door / Trunk Output
(-) PTS
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
(+)
(MUX)
(MUX)
(Data) Immo Data
(-) W2W Only - Hood Output
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Ref.
(+/-) Wire Color Ref.
403.HONDA7 2.19 2016 Honda Civic (Smart Key)
