Item
Part No.
No.
178499-901
1 Ref
2 Ref
3 Ref
4 Ref
5 Ref
6 Ref
7 Ref
8 Ref
9 Ref
10 Ref
11 Ref
12 Ref
13 Ref
14 178519-001
Description
Cylinder Assy, Swing, 14 inch/356 mm
Cylinder Cover, 14 inch
Solid State Swith Assy, 14 inch
Cylinder Bracker, 20 mm
SHCS 1/4-20x0.750 Lg
Washer Splitlock 0.250
BHCS M5x0.08x10mm Lg
BHCS M6x1.00x12mm Lg SS
FW M5 SS
LW M5 SS
Fastener M6 Lock Washer SS
Pinch Point Warning Label
1/4 Tube 1/8 NPT Elbow
Washer 1/4 inch (grade 8 steel)
Slide Assembly 350 mm Stroke
Notes
Includes all items shown in
Figure 28.
