Control Panel - Printronix SLPA7000e Training Manual And Reference Manual

2
The operation and system status of the SLPA are provided on the control
panel. Information concerning the SLPA is displayed on the liquid crystal
display (LCD), while commands are given to the SLPA through the control
panel keypad. Control valves are provided for refined adjustments to the
pneumatic system.
IMPORTANT
It is important to become familiar with all of the operations, readouts,
and components of the control panel. Inappropriate settings may impair
the SLPA's functionality.
Online
Status
Indicator
Liquid
Crystal
Display
(LCD)
Data
Indicator

Control Panel

Figure 13. Control Panel
