Chapter 1

Calibrating The Printer

Position the lower
media sensor in the
grey shaded area.
Avoid Pre-Printing
Avoid Rounded
Die Cut Label
Corner
Calibrating The Printer
For printers not using smart labels, an Auto Calibrate should be sufficient to
properly calibrate the printer (see next section).
To calibrate printers that are using smart labels:
1. Run an Auto Calibrate to set up initial values (page 21).
2. Make a Media Profile printout.
3. Make any necessary adjustments to Threshold Range in the CALIBRATE
CTRL menu.
4. Run an Auto Calibrate again (page 21).
5. Make a Media Profile printout again to verify the Threshold Range you
selected in step 3 is correct.
6. Save the configuration, and then set the saved configuration as the
Power-Up configuration (page 37).
20
FEED
