Printronix SLPA7000e Training Manual And Reference Manual page 65

Smart label printer applicator
Table of Contents

Advertisement

Item
Part No.
No.
1
Ref
2
Ref
3
Ref
4
Ref
5
178631-001
6
178632-001
7
Ref
8
Ref
9
Ref
10
Ref
11
Ref
12
Ref
13
178520-001
14
178521-001
15
Ref
16
Ref
17
178633-001
18
Ref
19
Ref
20
Ref
21
Ref
22
Ref
23
178522-001
Description
Gauge Clamp
Manifold, 1.250 inch Reg. Spacing
1/8 NPT Pipe Plug, Socket H
Close Nipple 1/8 NPT
Pressure Gauge, 100 psi
Vacuum Gauge, 30 hg
1/4 x 0.159 Tubing-Blue Polyurethane
1/4 Tube 1/8 NPT Elbow
#10 Male Elbow Fitting
#10 Male Fitting
Air Cyl. Piston Rod Clevis
Double Acting Air Cyl. 9/16 x 4
Valve, Air Cyl., 3 Way with Diode
Valve, Air Cyl., 4 Way with Diode
Regulator (3)
Flow Control, Inline
Filter/Mist/Reg. Combo
Bulkhead Union, 1/4 OD Tube to
1/4 OD Tube
Check Valve
Branch Tee, 1/4 Tube 1/8 NPT
Adapter 1/8 NPT F to #10-32 M
1/4 Tube to #10-32 M Elbow (4)
Vacuum Generator
