Vehicle Connections - Directed DS4+ Installation Manual

Vehicle connections

The connection information listed below is specific to the 2010 Toyota Camry (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Main harness, 12-pin black connector (H1)
Module
Conn./Pin Color
H1/1 Blue/White
H1/2 Blue/Red
H1/3 Blue
H1/4 White/Brown
H1/5 White
H1/6 Red
H1/7 Lt. Green/Red
H1/8 Lt. Green
H1/9 Lt. Green/White
H1/10 Black
H1/11 White
H1/12 Red
Relay harness, 10-pin white connector (H2)
Module
Conn./Pin Color
H2/1 N/A
H2/2 Red/Black
H2/3 Pink/Black
H2/4 Pink/White
H2/5 Red
H2/6 Green
H2/7 Violet
H2/8 Orange
H2/9 Red/White
H2/10 Pink
Data harness, 8-pin white connector (H3)
Module
Conn./Pin Color
H3/1 Tan
H3/2 Tan/Black
H3/3 Orange/Brown
H3/4 Orange/Green
9
Description
Relay N.C. No Connection
Relay N.O. STSW
Relay COM STSW
Relay N.C. No Connection
Relay COM Clutch Activation Output
No Connection
Relay N.O. No Connection
Relay COM Auto Light
Relay N.C. Auto Light
No Connection
Relay COM No Connection
No Connection
Description
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Description
(Data) HS CAN Low
(Data) HS CAN High
No Connection
No Connection
Connects To
Wire Location
No Connection
Body ECU on back of dash fuse box, white 10 pin plug, pin 4
dash fuse box, white 1 pin plug (A), pin 1
No Connection
clutch switch, black 2 pin plug, pins 1 and 2
No Connection
No Connection
headlight switch, white 20 pin plug, pin 19
headlight switch, white 20 pin plug, pin 19
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
data link connector, black 16 pin plug, pin 14
data link connector, black 16 pin plug, pin 6
No Connection
No Connection
(+/-) Wire Color Ref.
+ gray
+ black (120A)
+
red (in), green (out)
N.O.
cut green
cut green
(+/-) Wire Color Ref.
(+/-) Wire Color Ref.
data white
data black
933.TL1 5.03.185 2010 Toyota Camry (Smart Key)
© 2017-10-17 Directed. All rights reserved.
