Directed DS4+ Installation Manual page 11

RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color
H7/1 Black
H7/2 Black
11
Color
N/A
N/A
Color
Blue
Black
Green
Red
Description
Temperature Sensor
Temperature Sensor
Description
Description
Connects To
Wire Location
No Connection
No Connection
(+/-) Wire Color Ref.
933.TL1 5.03.185 2010 Toyota Camry (Smart Key)
