Wiring Diagram - Directed DS4+ Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Headlight Switch
(white conn.
at headlight switch)
10 9 8 7 6 5 4 3 2 1
19
20 18 17 16 15 14 13 12 11
Autolight: (-) Parking Lights:
Green or Yellow, pin 19 Black or Lt. Blue, pin 18
Main Body ECU
(white conn.
under drivers dash)
CUT
7
(-) Push-To-Start:
Blue or Pink, pin 7
ENGINE
7
START
1 6 5 4 3 2 1
STOP
14 13 12 11 10 9 8
PTS Switch
(black conn.
behind PTS button)
2 1
6 5 4 3
10 9 8 7
Siren
Hood Pin
OR
(+) STSW: Pin 4 or 6
(+) 12V,
Black or White,
pin 1
1
Dash Fuse Box
(white conn.)
OBDII
Diagnostic
Connector
HS CAN High: Pin 6
1 8
9 16
HS CAN Low: Pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) Parking Light Output: Lt.Green/Black: 1
(-) Push-to-Start Output: Lt.Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) 12V Input: Blue/Red: 2
(+) Start Stop Switch Output: Blue: 3
(+) 12V Input: Red: 6 &12
Autolights Interrupt (veh. side): Lt.Green: 8
Autolights Interrupt (conn. side): Lt.Green/White: 9
(-) Ground: Black: 10
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
