Digital Projection HIGHlite Laser II 3D Series

Electrical and physical specifications

Mains Voltage
Operating Temperature
Storage Temperature
Operating Humidity
Weight
Power Consumption
Thermal Dissipation

Laser precautions

CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reflected toward other people or
reflective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
Non-laser emission. There remains non-laser emission from the projection lens. This
portion of emission has been tested per IEC/EN 62471 to be Risk Group 2 (Low Risk).
Laser Parameters:
Wavelength
Laser Power for classification
Total internal power
Apparent Source Size
Divergence
Rev C April 2017
200-240 VAC 9 A 50/60 Hz (single phase)
110-130 VAC 11.5 A 50/60 Hz (single phase)
0°C to 35°C
-20°C to 60°C
20% to 90% non-condensing
58 kg (127.9 lb) without lens
1705 W at 200 VAC, 1145 W at 110 VAC
5850 BTU/hr at 200 VAC, 3929 BTU/hr at 110 VAC
450 nm - 460 nm
333.5 mW
> 100 W
> 10 mm at lens stop
100 miliRadian
Important Information
Page 5
