Location of laser aperture
The laser aperture
Interlock switches
Five interlock switches installed at the main frame, inside the cover, will power-off the system
individually when activated.
Will be activated when the filter cover is removed.
1
Will be activated when the top cover is removed.
2
3
Will be activated when the projection lens is removed.
4
(x2) Will be activated when the lens hood is removed.
Page 8
is located as indicated below.
1
1
1
3
4
Digital Projection HIGHlite Laser II 3D Series
2
Rev C April 2017
