Digital Projection E-Vision Laser 4K Series

Electrical and physical specifications

Main Voltage
Operating Temperature
Storage Temperature
Operating Humidity
Dimensions:
Weight
Power Consumption
Thermal Dissipation

Laser precautions

CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reflected toward other people or
reflective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 450nm - 460nm (Blue)
Mode of operation Pulsed, due to frame rate
Pulse width 0.74ms
Pulse repetition rate 240Hz
Maximum laser energy 0.376mJ
Total internal power 240Wmax
Apparent source size >10mm, at lens stop
Divergence >100 mili Radian
Rev A June 2017
100-240 VAC 50/60Hz (Switch selectable)
5°C to 40°C (41 F to 104 F)
-10°C to 60°C (14 F to 140 F)
10% to 85% non-condensing
W 500 mm (19.7 in), H 218 mm (8.6 in), D 598 mm (23.5 in)
29 kg (63.9 lb) without lens
at 100 VAC: 920 W max
at 240 VAC: 880 W max
Standby power: < 6W (normal), <3W (ECO), <0.5W (PowerSAVE)
at 100 VAC: 3139 BTU/Hour max
at 240 VAC: 3002 BTU/Hour max
Important Information
Page 5
