  • Page 1 User Manual...

  • Page 3: Table Of Contents

    Contents of this User Manual Introduction Thank you Training Symbols used in this documentation Safety and compliance General safety considerations Information/Warning - Potential Mercury Vapour Health Issues FCC compliance Disposal information 2.4.1 Statement WEEE (Waste Electrical and Electronic Equipment) 2.4.2 Disposal of batteries in the product 2.4.3 Turkey RoHS compliance...
  • Page 4 On screen display (OSD) messages 6.7.1 Disabling the STATUS indicator 6.7.2 Setting the background color 6.7.3 Setting OSD menu timeout 6.7.4 Selecting the startup logo PIN code Disabling the wireless remote control (IR) receivers 6.10 Software upgrades iVision50-series User Manual - Introduction...
  • Page 5 Optimising the image Calibration data 7.1.1 Updating ColorMax calibration data 7.1.2 ColorMax modes Setting a white point or color temperature 7.2.1 Defining the system color gamut Gamma Technical specifications Lamp change...
  • Page 6 User Manual - Introduction...

  • Page 7: Thank You

    1 Introduction 1.1 Thank you Thank you for purchasing this projector. When referring to the term xVision50 in this document,iit means that the content is applicable for the following DPI products: • iVision50 HD (1920x1080) • iVision50 WUXGA (1920x1200) • iVision50 PN (2560x1080) The iVision50 series projectors set an industry benchmark for projectors in its size and performance category.
  • Page 8 User Manual - Introduction...

  • Page 9: Safety And Compliance

    2 Safety and compliance 2.1 General safety considerations • Use only the cables and cords supplied with the projector or original replacement cables. Using other cables or cords may lead to malfunction and permanent damage to the unit. • Always use 3-prong (grounded) power cord to ensure proper grounding of the unit. Never use 2-prong power cords, as this is dangerous and could lead to electrical shock.

  • Page 10: Fcc Compliance

    (2) This device must accept any interference received, including interference that may cause undesired operation. CANADA This Class A digital apparatus complies with Canadian ICES-003. / Cet appareil numérique de la classe A est conforme à la norme NMB- 003 du Canada. iVision50-series User Manual - Safety and compliance...

  • Page 11: Disposal Information

    2.4 Disposal information 2.4.1 Statement WEEE (Waste Electrical and Electronic Equipment) This symbol on the product indicates that, under the European Directive 2012/19/EU govern- ing waste from electrical and electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by handing it over to a designated collection point for the waste recycling of electrical and electronic equipment.
  • Page 12 User Manual - Safety and compliance...

  • Page 13: What's In The Box

    3 What’s in the box? The following components are standard delivery: Projector Power Cable (Country Dependent) Remote Control User Documentation Additional accessories available for the projector: Exhaust air kit (for ceiling mount) A: Air-inlet filter (also sold separately) B: Side cover/Air-inlet C: Ceiling mount cover/Air-outlet (also sold separately) D: Exhaust air duct*...
  • Page 14 User Manual - What’s in the box?

  • Page 15: System Considerations

    4 Installation 4.1 System considerations Please see Chapter 5 Overview for explanation on the various features of the projector. Installation should only be performed by trained and skilled personnel in order to achieve the desired results. Safety first: Projectors and other equipment that are not mounted properly represent a potential danger to people and may result in injury or death! Creating a successful system installation requires proper skills, competencies and knowledge of the particular system requirements.

  • Page 16: Ventilation Accessories

    A set of optional asseccories is available for this projector, covering anything from cables and lenses to air flow parts and lens control. For information on availability, specifications and pricing, please refer to our web site. iVision50-series iVision50-series User Manualal - Introduction...

  • Page 17: Locking The Projector

    4.3 Ceiling and rig mounting Use the three mounting holes provided in the bottom part to securely fix the projector to a ceiling or rig mount. Use M6 screws that protrude maximum 9mm into the projector body. Figure 4-2. Ceiling/rig mounting mounting holes 4.4 Locking the projector The projector can be locked physically by using a so called Kensington lock.

  • Page 18: Selecting A Lens

    Please keep the caps on until mounting the lens on the projector! Remove lens protection caps before mounting the lens and using the projector. Release button Figure 4-5. Projection lens release button iVision50-series iVision50-series User Manualal - Introduction User Manual - Installation...

  • Page 19: Lens Range

    4.6.1 Inserting a lens Remove the protection lid on the projector by turning the lid anti-clockwise until it comes loose Remove the protection lids from the lens Insert the lens, making sure the red line marking on the lens points straight up towards the top of the cabinet.

  • Page 20: Lens Shift

    Using the remote control, press the OK key to center the lens or arrow keys to position it (restricted downwards movability). • Using the RS-232 or LAN control interfaces, please refer to the relevant SIS (Simplified Instruction Set) commands available for download on our website. iVision50-series iVision50-series User Manualal - Introduction User Manual - Installation...

  • Page 21: Lens Planarity (Scheimpflug Adjustment)

    4.9 Lens planarity (Scheimpflug adjustment) This adjustment is rarely needed, do not apply it unless it is required. Certain applications require fine adjustment of the lens planarity in order to obtain an image that is focused. The projector is fitted with three adjustment screws (Allen key 3mm/5mm) around the bayonet mount that facilitate such adjustment, a so called Scheimpflug adjust- ment.

  • Page 22: Making The Connections

    If using 3rd party system equipment, such as signal repeaters or switchers, please make sure that EDID (Extended Display Identification Data) information is not lost in translation. Wrong EDID data may result in distorted images, wrong aspect ratios or reduced image resolutions. iVision50-series iVision50-series User Manualal - Introduction User Manual - Installation...

  • Page 23: Image Sizes

    4.15 Image sizes 2560 x 1600 (WQXGA) Screen diagonal Image width 15.00 12.00 7.50 13.75 7.00 11.00 12.50 6.50 10.00 6.00 11.25 9.00 5.50 10.00 8.00 5.00 8,75 4.50 7.00 4.00 7.50 6.00 3.50 6.25 5.00 3.00 5.00 2.50 4.00 2.00 3.75 3.00...
  • Page 24 User Manualal - Introduction User Manual - Installation...
  • Page 25 5 Overview Remote Control Receiver Interchangeable Projection Lens Projection Lens Release Button Figure 5-10. Projector front Remote Control Receiver Hot Air Exhaust Signal and Control Connector Panel Mains Power Connector Figure 5-11. Projector rear Keypad Figure 5-12. Projector top...
  • Page 26 Accessory Mounting Features Ceiling/Rig Mounting Features Figure 5-13. Mounting features Lamp Door Air Inlet Figure 5-14. Projector left and right hand side User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 27: Keypad And Indicator

    5.1 Keypad and indicator Figure 5-15. Projector top key pad VALUE POWER Power on or power off (standby) MENU Activate or deactivate on-screen menu system UP, DOWN, LEFT, RIGHT Select source when not in Shift or Menu mode Shift lens when not in Menu and after SHIFT/OK pressed Navigate when in Menu system SHIFT/OK Shift lens when not in menu system...

  • Page 28: Wireless Remote Control

    Activates lens shift function Reserved for future use OK/ARROWS Confirms the selection / Directional navigation tools BACK Returns to previous alternative MENU Activates the projector menu SOURCE Toggles between available sources (forward/backwards arrows) User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 29: Control Connectors

    5.3 Connectors Figure 5-17. Connector panel (see technical data for details) 5.3.1 Signal connectors CONNECTOR CONNECTOR FUNCTION NAME TYPE HDBaseT RJ45 Video over twisted pair DVI-I*) dual link Digital video (dual-link) HDMI HDMI type A Digital video DP (Display Port) DP Digital video (2) 9 pin mini DSUB Analog RGBHV video 3G-SDI...

  • Page 30: Menu System

    Pre-stored, and user defined settings. language: Selects menu language. status: System information. The top level menu item 3D is only visible for Active Stereo 3D enabled projectors. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 31: D Main Menu

    5.5 3D main menu The 3D menu contains settings for turning 3D on and off, in addition to defining various aspects of setup using Dual Head and specifying the types of glasses to be used. 3D : Offers the possibility to switch the 3D function off and to chose between the following alternatives for setup: off, side by side (60Hz<...

  • Page 32: D > Dual Head Setup Sub Menu

    DVI (DL) 3G SDI 3 G SDI HDBaseT DVI (Single Link Mode) HDMI DVI (Dual Link Mode) 3G SDI (A) 3G SDI (B) Not possible Possible Figure 5-18. Dual head setup possibilities User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 33: Picture Main Menu

    DICOM, custom, advanced. If the profile is marked by an asterisk (*), this indicates that the original settings have been changed. ColorMax: Digital Projection’s proprietary color management suite. See decription in ColorMax sub menu. gamma: 10 predefined gamma curves: Film 2.2: Exponential 2.2 curve...

  • Page 34: Picture > Colormax Sub Menu

    (red, green, blue, white, black, cyan, magenta, yellow). Presents measured values for ColorMax (see below). Calibration settings have to be made individually for each separate profile. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 35: Picture > Advanced Sub Menu

    5.6.2 Picture > Advanced sub menu horizontal position: Shifts the image sideways (VGA only) vertical position: Shifts the image up or down (VGA only) phase: Adjust for stable image. A jittery image may appear with certain VGA sources. You may also press the AUTO button on the keypad or remote control to optimize.

  • Page 36: Installation Main Menu

    (enables receiving signals via longer cables/with a higher bit rate) DisplayPort 2 eq Choice between Normal and High (enables receiving signals via longer cables/with a higher bit rate) EDID : Sub menu for EDID. synchronization: Sub menu for synchronization. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 37: Installation > Edid Sub Menu

    5.7.1 Installation > EDID sub menu VGA : Define the detailed timing descriptor in the EDID data for VGA connector. Select between auto, WUXGA, 1080@60Hz, SX+, SXGA, 1366x768, 720@60Hz, 720@50Hz, XGA, SVGA, VGA. DVI : Define the detailed timing descriptor in the EDID data for DVI connector. Select between auto, WQXGA@60Hz, WUXGA@120Hz, WUXGA@60Hz,1080 @120Hz, 1080@60Hz, SX+, SXGA, 1366x768, 720@60Hz, 720@50Hz, XGA, SVGA, VGA.

  • Page 38: Installation > Synchronization Sub Menu

    If you use one of the sync connectors as 2D or 3D sync input, this may block the use of the same connector as output. For further info on the various possible user scenarios, please refer to our web page. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 39: Settings Menu

    5.8 Settings menu PIN code: Protect the projector from usage with a PIN. If enabled the projector will ask for the PIN at every start up. network : Set IP address, Subnet mask and default gateway TCP/UDP port number. DHCP is supported and is enabled by default, but can be disabled. factory reset: Restore all settings to the factory defined values.

  • Page 40: Settings > Pin Code Sub Menu

    To change the PIN code you first have to enter the current PIN code (Default PIN: 1234). Then you enter a new 4 digit code and confirm this code by entering the same code again. Click OK and the new code is set. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 41: Settings > Network Sub Menu

    5.8.2 Settings > Network sub menu change LAN settings: In this sub-menu you can switch the DHCP enabled function on or off. If off you can set a fixed IP-address. LAN DHCP: DHCP is supported and is enabled by default, but can be disabled under change LAN settings LAN IP address: Info field stating the current LAN IP address.

  • Page 42: Settings > Factory Reset Sub Menu

    5.8.4 Settings > Service sub menu service: Restricted area with information intended for qualified service personnel only enter code: Enter the 5-digit access code to gain assess to the service information. User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 43: Languages Menu

    5.9 Languages menu Select the desired menu language. • Supported languages: English, French, German, Spanish, Norwegian, Swedish, Russian, Korean, Japanese,Chinese Traditional, Chinese Simplified, Portuguese, Italian. • Default: English...

  • Page 44: Status Menu

    Remaining lamp time. lamp time: Lamp time used. total operating: Total operating time for projector. lamp power: Lamp power in watts. IP address LAN: Projector IP address for use in network/remote control . User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 45: Status > Source Information Sub Menu

    5.10.1 Status > Source Information sub menu advanced: Access to sub menu for more settings depending on source used. See 4.10.2 Status > Source Information > Advanced sub menu source: Info on which source is in use. brightness: Info on brightness settings. contrast: Info on contrast settings.

  • Page 46: Status > Source Information > Advanced Sub Menu

    Info on current horizontal and vertical image size. active image size: Info on current active image size. scan: Projector serial number. pixelclock: Week of manufacturing. mode id: Info on current mode setup (VGA source only). User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 47: Status > Source Synchronisation Sub Menu

    5.10.3 Status > Source Synchronisation sub menu Indicates which 3D mode is used. 2D frame lock: Indicates what the projector locks to in 2D Frequency: Shows the current frequency of the locking signal Status: Indicates the locking status Phase: Indicates phase between the source and the locking signal 3D source sync: Indicates where the source L/R sync is connected Frequency:...
  • Page 48 User Manual - Introduction iVision50-series User Manual - Overview...

  • Page 49: Image Alignment

    6 Functionality The various functions of the projector are described in detail in the following chapters. 6.1 Powering On and Off 6.1.1 Manual power control Switch the projector between On and Standby using the POWER switch on the keypad or the wireless remote control.

  • Page 50: System Status

    For manual override of the automatically detected color space and digital level, go to PICTURE > ADVANCED in the menu. Set the COLOR SPACE and INPUT LEVEL to one of the manual settings, choosing your desired color space and digital drive level. User Manual - Introduction iVision50-series User Manual - Functionality...

  • Page 51: Lamp Power

    6.5 Lamp power The projection lamp can be run at different power levels. The lowest power is called ECO mode. Higher levels give higher brightness and shorter lamp life time. Lower levels save energy, extend lifetime and reduce brightness. In the menu system, go to INSTALLATION > LAMP >...

  • Page 52: Pin Code

    Do not remove the power cord while the upgrade is still in progress! The projector may restart several times during the upgrade • • The upgrade has finished successfully when yellow rapid blink has changed to stable yellow light User Manual - Introduction iVision50-series User Manual - Functionality...

  • Page 53: Optimising The Image

    7 Optimising the image The projector has powerful features for picture optimization. This chapter describes details in using these features. All color calibration is done using Digital Projection’s proprietary Color- Max solution. 7.1 Calibration data All our projectors are measured and calibrated with high precision equipment at the factory for the best out-of-box experience.

  • Page 54: Colormax Modes

    Red, Green, Blue, Cyan, Magenta, Yellow, White. In this mode color points and intensity for each color can be manipulated separately. To change the ColorMax mode please go the menu PICTURE > COLORMAX > DESIRED VALUES > DESIRED COORDS MODE. iVision50-series User Manual - Optimising the image...

  • Page 55: Setting A White Point Or Color Temperature

    7.2 Setting a white point or color temperature After enabling ColorMax set the color temperature in the menu PICTURE > COLORMAX > COLOR TEMPERATURE. Values between 3200K and 9300K can be selected. These color temperatures are tracking the “black body curve”- the black curved line in the center of CIE Chart in Figure 7-7.
  • Page 56 The names of the curves are descriptive for their recommended use. Using any of the computer curves for video applications will results in significant image noise. Figure 7-1. Film 2.2 gamma Figure 7-2. Film 2.4 gamma Figure 7-3. Film 2.6 gamma iVision50-series User Manual - Optimising the image...
  • Page 57 Figure 7-4. Film 2.8 gamma Figure 7-5. Video 1 gamma Figure 7-6. Video 2 gamma...
  • Page 58 Figure 7-7. Computer 1 gamma Figure 7-8. Computer 2 gamma Figure 7-9. Dynamic gamma iVision50-series User Manual - Optimising the image...
  • Page 59 Figure 7-10. DICOM 180 Lux* (example HB color wheel: other shapes with other alternatives) * Several DICOM settings (10, 60, 180, 250, 400 Lux - The higher Lux number (ambient light), the steeper the curve.
  • Page 60 User Manual - Optimising the image...

  • Page 61: Technical Specifications

    8 Technical specifications Please see www.digitalprojection.com for more technical information.
  • Page 62 User Manual - Technical specifications...

  • Page 63: Lamp Change

    9 Lamp change The indicator on the keypad will turn RED when lamp life is expired. Change the lamp when lifetime expires. Always replace lamp with the same type and rating. USE ORIGINAL LAMPS ONLY. The lamp holder employs an electronic lamp timer that is tracking the life time of the lamp.
  • Page 64 User Manual - Lamp change...
  • Page 66 North America Corporate Headquarters Digital Projection, Inc. 55 Chastain Road, NW, Suite 115 Kennesaw, GA 30144 (P) 770.420.1350 (F) 770.420.1360 Worldwide Headquarters Digital Projection Ltd. Greenside Way, Middleton, Manchester M24 1XX (P) +44 (0) 161 947 3300 (F) +44 (0) 161 684 7674...
