Fig. 16: Downloading code via XModem through Windows Hyperterminal

4.4 Connector specifications

4.4.1 Twisted pair connections (RJ45)

RJ45 LAN

4.4.2 WAN Connector

Note
Cables used for multi-purpose Teldat drivers must not be used in these connections. You must use
end-to-end pin-to-pin connector cables.
ATLAS 300 Installation Manual
RJ45 PIN
1
2
3
4
5
6
7
8
Ethernet
Tx+(input)
Tx-(input)
Rx+(input)
--
--
Rx-(output)
--
--
4 Appendices
