4 Appendices
• Once the transfer has successfully completed, the WAN1 LED turns green and the S LED keeps flashing yellow,
indicating that recording is in progress. If the S LED turns red, the recording process failed; if it turns green, the re-
cording process completed successfully.
• Once the code has been successfully loaded, deactivate microswitch c to prevent the device from entering wait
mode when downloading the code via XModem.
Note
By default, the application loaded via XModem is saved as APPCODEI.BIN. You can change this name
by following the instructions that appear on the console during downloading.
You can also access the BIOS menus to load through the console. To access these menus, press
CTRL-T when a series of dots appear after the >> symbols.
===========================================================================
BIOS TELDAT
===========================================================================
BIOS CODE VERSION: 01.00
CLK=294912 KHz
Date: 04/21/04, Wednesday
SDRAM size: 128 Megabytes
BANK 0: 128 Megabytes (detected)
Caches: ON
FLASH: 16 Mb.
NVRAM: 128 Kb.
EEPROM: 2048 Bytes.
DPRAM: 16384 Bytes.
WAN1: DCE
WAN2: DTE
WAN3: DCE
FAST ETHERNET 1
FAST ETHERNET 2
PCI device: Host bridge
(Bus: 0, Device: 0, Function: 0)
Current production date: 03 49
Current software license: 6 4
Current serial number: 472/06547
Current file name: APPCODE1.BIN
Press Ctrl+t to change file name
........
Xmodem whith chk transfer. Default baud rate: 115200
Press any key to change the baud rate
...o.
Select the baud rate transfer:
1. 9600
2. 14400
3. 19200
Press 0 to abort load...
4
Set baud rate to 38400 and send the file with Xmodem with chk protocol.
When the transfer finish, reset baud rate to 9600.
Changing the transfer speed
18
BUSCLK=65536 KHz L255
Time: 11:50:48
Write-Back
4. 38400
5. 57600
6. 115200
