on command. The device will restart approximately 30 seconds after leaving the FTP session.
C:\atl>ftp 172.24.78.94
Connected to 172.24.78.94.
220 FTP server ready, 1 active clients of 1 simultaneous clients allowed.
User (172.24.78.94:(none)): root
331 User name accepted, need password.
Password:
230 User login complete.
ftp> dir
200 PORT is set to IP ADDR = 172.24.51.23
150 Data connection open, list transfer in process...
-rwxrwxrwx
-rwxrwxrwx
226 List transfer completed, data connection is closed.
395 bytes received in 0,16 seconds (2,47 Kbytes/sec)
ftp> binary
200 TYPE is set to IMAGE.
ftp> hash
Hash mark printing On (2048 bytes/hash mark).
ftp> put at300.bin
200 PORT is set to IP ADDR = 172.24.51.23
150 Data connection open, file transfer in process...
################################################################################
################################################################################
################################################################################
################################################################################
################################################################################
################################################################################
##################################################
226 STOR completed, 2167348 bytes processed, data connection is closed.
2167348 bytes sent in 2,72 seconds (795,65 Kbytes/sec)
ftp> quote site statbuffer
211 Buffer status: MAX-REQ-BUSY 3145728-2179072-2167348 filename: "AT300.BIN"
ftp> quote site savebuffer
200 SAVEBUFFER completed O.K.
ftp> quote site reload on
200 RELOAD mode is set to ON.
ftp> bye
221 Goodbye.
C:\atl>
Loading the code via FTP from a Windows MSDOS screen
If you need help, you can use the standard FTP help command to get a list of commands (not all are operational on
this server). Entering help <command_name> provides help on the specified command. For further information,
please check the Dm724-I FTP Protocol manual.
Thanks to the quote site statbuffer command, you can view the status of the buffer at any time. If you wish to delete
it, use the quote site clearbuffer command.

4.3.2 Updating via XModem

This updating method is recommended when there is no IP connection to the device or in case of an emergency.
To update:
• Set microswitch c in the ON position and switch the device on. The transfer speed is 115200 bps by default. To
change the speed, you must access the device console and set the new speed (the following figure shows you
how to do this).
• Wait until the WAN1 LED is green and the S LED is slowly flashing yellow. The device is waiting to load the code.
• Load the application file using a program that can send data via the XModem protocol. You will notice that the S
LED is flashing rapidly, indicating that the transfer is in progress. If the S LED turns red, the transfer has failed. Re-
peat the process slowing down the speed.
ATLAS 300 Installation Manual
1 ftp ftp 2163872 Nov 27 2001 AT300.BIN
1 ftp ftp 4727 Nov 27 2001 ROUTER.CFG
PORT = 1964
PORT = 1965
