User Manual
Ascom Myco Smartphone
• see 11.2 Color-Coded LED Signals, page 68
display.
3.1.9

Ascom IR location

The Ascom Myco handset is capable of using IR-positioning with the Ascom IR Location feature.
3.1.10

Color Pad for Clip

The color pad on top of the clip is used to differentiate the handsets between, for example, workgroups,
shifts, or roles. The blue color pad is attached by default, and it can be exchanged for one of the colors, red,
yellow, or green. See 18.3 Replace the Color Pad for the Hinge-Type Clip, page
3.2

Accessories

The following accessories are available for the handset:
Battery pack
Spare clip
Safety cord
Color pad kit for clip
CR5 Charging rack
CR6 Battery charging rack
Table adapters for charging rack (CR5/CR6)
Micro-USB cable
USB power supply
12. Only available for Ascom Myco 2.
TD 93066EN / 14 December 2018 / Ver. N
for details on how other notifications are shown in the top
12
A replacement battery pack may be replaced and
charged separately in the battery charging rack,
which is the quickest way to charge.
The replacement hinge-type clip is especially
designed to fit one-layered fabric, such as shirt
pockets.
The safety cord is attached around the clip to
prevent from dropping the handset.
The color pad is attached to the clip, and is used to
easily identify the handset belonging to, for
example, a workgroup, shift, or role.
The charging rack (CR5) charges up to six handsets
at the same time.
Charging time (fully depleted battery): Approx. 3.5
hours.
The battery charging rack (CR6) charges up to six
battery packs at the same time.
Charging time (fully depleted battery): Approx.3
hours.
With the attachable feet the charging rack can be
placed on a table, instead of being wall mounted.
The Micro-USB cable, attached to the USB power
supply, charges one handset at a time, for example
at your own desk. When connected to (an active)
computer, the USB cable can also be used to
charge the handset, or for troubleshooting.
Charging time (fully depleted battery): Approx. 4.5
hours.
The USB power supply is used with the Micro-USB
cable, for charging in a wall socket.
Handset Description
87.
