Submode 4: DESCRIPTOR PROGRAMMING

Press [∗] [BYPASS] while in Installer Mode 1, then press [4] to enter Descriptor Programming submode.
To create a descriptor:
1. Press [∗] then the Question number representing the zone number desired.
2. Press the INSTANT key to move the cursor to the desired location within that question.
3. Press one of the character display keys (see table below) to display the character set.
4. When the desired character appears, press INSTANT. The character is accepted and the cursor moves
to the next location. To move to a previous location to change a character, if needed, press CODE.
5. When the descriptor is complete, accept the entry by pressing [∗] then the next question number.
Refer to the following chart when entering descriptors:
Key
INSTANT
CODE
[7]
[9]
[#] [7]
[#] [9]
[8]
[0]
QUESTION 01-48 ZONE DESCRIPTORS FOR ZONES 01-48
L1 L2
These questions allow you to enter up to 16 descriptor digits for each zone. Each digit corresponds to a single
descriptor character. Use the separate Programming Form to enter the actual descriptors for each zone.
Q 01
Q 02
Q 03
Q 04
Q 05
Q 06
Q 07
Q 08
Q 09
Q 10
Q 11
Q 12
Q 13
Q 14
Q 15
Q 16
Q 17
Q 18
Q 19
Q 20
Q 21
Q 22
Q 23
Q 24
QUESTION 49-51 PARTITION DESCRIPTORS
L1 L2
These questions allow you to enter up to 16 partition descriptor digits for partitions 1-3. There is no
provision for the common partition descriptor. Each digit corresponds to a single character in the descriptor.
Q 49 DESCRIPTOR FOR PARTITION 1
Q 50 DESCRIPTOR FOR PARTITION 2
Q 51 DESCRIPTOR FOR PARTITION 3
Function
Accepts displayed character and moves cursor forward one position.
Moves cursor backward one position.
Displays next character in character set.
Displays previous character in character set.
Automatically scrolls character set display forward.
Automatically scrolls character set display backward.
Stops auto scrolling.
Inserts a blank character.
L3 L4 L5 L6
DESCRIPTOR FOR:
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
ZONE 7
ZONE 8
ZONE 9
ZONE 10
ZONE 11
ZONE 12
ZONE 13
ZONE 14
ZONE 15
ZONE 16
ZONE 17
ZONE 18
ZONE 19
ZONE 20
ZONE 21
ZONE 22
ZONE 23
ZONE 24
L3 L4 L5 L6
L7 L8 L9 L10
DESCRIPTOR FOR:
Q 25 ZONE 25
Q 26 ZONE 26
Q 27 ZONE 27
Q 28 ZONE 28
Q 29 ZONE 29
Q 30 ZONE 30
Q 31 ZONE 31
Q 32 ZONE 32
Q 33 ZONE 33
Q 34 ZONE 34
Q 35 ZONE 35
Q 36 ZONE 36
Q 37 ZONE 37
Q 38 ZONE 38
Q 39 ZONE 39
Q 40 ZONE 40
Q 41 ZONE 41
Q 42 ZONE 42
Q 43 ZONE 43
Q 44 ZONE 44
Q 45 ZONE 45
Q 46 ZONE 46
Q 47 ZONE 47
Q 48 ZONE 48
L7 L8 L9 L10
L11 L12 L13 L14
L11 L12 L13 L14
L15 L16
L15 L16
6-49
