INSTALLATION
INSTRUCTIONS
FA162C
2-PARTITIONED SECURITY SYSTEM
Principal changes between the FA162C and the
former FA160C are indicated by margin lines.
N7526-1V3 8/97

Advertisement

Table of Contents
loading

Related Manuals for First Alert FA162C

Summary of Contents for First Alert FA162C

  • Page 1 INSTALLATION INSTRUCTIONS FA162C 2-PARTITIONED SECURITY SYSTEM Principal changes between the FA162C and the former FA160C are indicated by margin lines. N7526-1V3 8/97...
  • Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations For The Location Of Fire And Burglary Detection Devices Help Provide Proper Coverage For The Protected Premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section 1. GENERAL DESCRIPTION ..................... 7 Section 2. INSTALLING THE CONTROL ..................10 Mounting the Cabinet ......................10 Installing the Lock (if used) ..................... 10 Mounting the Control's Circuit Board Alone in the Cabinet........... 11 Mounting Control and RF Receiver Circuit Boards Together in the Cabinet ....11 Standard Phone Line Connections..................
  • Page 4 Section 8. FA4285 PHONE MODULE .................... 32 Installing the Phone Module ..................... 32 General Information ....................... 32 Mounting The Phone Module ..................32 Phone Module Wiring ..................... 33 Caller ID Units ....................... 33 Checking the Operation of the FA4285 Phone Module............ 35 Section 9.
  • Page 5 Figure 18.ÊÊLong Range Radio Connections............38 Figure 19. NOT USED Figure 20.ÊÊConnection of AAV Unit Without an FA4285 Phone Module ..40 Figure 21.ÊÊConnection of AAV Unit With an FA4285 Phone Module ....40 Figure 22.ÊÊFA162C Summary of Connections ......Inside Back Cover –5–...
  • Page 6 CONVENTIONS USED IN THIS MANUAL MAIN SECTION TITLES ARE SHOWN IN REVERSE TYPE Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons). These notes include specific information which must be followed if you are installing this system for a UL Listed application.

  • Page 7: General Description

    Section 1. GENERAL DESCRIPTION The FA162C is a 2-partition control that supports up to 38 zones, using basic hard-wired, wired expansion, and/or wireless zones, plus 3 keypad activated zones. Basic Hardwired Zones Provides 8 basic hardwired zones having the following characteristics: ¥...
  • Page 8 Security Codes ¥ One installer code for entire system (user 1) ¥ One Master code for each partition (user 2) ¥ 12 secondary user codes for each partition (users 3Ð14) ¥ One baby-sitter code for each partition (user 15) ¥ One duress code for each partition (user 16) Baby-sitter Code: A special code that can only be used to disarm the system if that particular code was used to arm it.
  • Page 9 Optional Long Range Radio ¥ Allows all messages that have been programmed to go to the primary telephone number to be reported additionally to a 7720PLUS or 7820 radio. Check availability of these models. Built-in Telephone Line Monitoring Option ¥ The telephone line voltage can be monitored to supervise the phone line connection.

  • Page 10: Installing The Control

    Section 2. INSTALLING THE CONTROL This section provides instructions for mounting the control cabinet, and installing the cabinet lock (if used). Also included in this section are instructions for the following: ¥ Installing the main PC board ¥ Mounting the 5881 (5882 in Canada) RF Receiver board in the cabinet (if used) ¥...

  • Page 11: Mounting The Control's Circuit Board Alone In The Cabinet

    Mounting The Control's Circuit Board Alone in The Cabinet (Fig. 2) 1. Hang two short Black mounting clips (provided) on the raised cabinet tabs (see Detail B in Fig. 2). 2. Insert the top of the circuit board into the slots at the top of the cabinet. Make sure that the board rests on the correct row (see Detail A ).

  • Page 12: Standard Phone Line Connections

    Standard Phone Line Connections The wiring connections shown here are not applicable if the FA4285 Phone Module is used. Refer to the FA4285 Phone Module section for information regarding phone line connections, which are different than those shown here. Incoming phone line and handset wiring is connected to the main terminal block (via a RJ31X jack) as follows (also see Figure 4): Term.

  • Page 13: Installing The Back-Up Battery

    b. Wire the other three terminals (Sync, Data, Com) on the 4300 transformer. Wires from these terminals must be connected to a 9-pin connector on the control board (using a 4142TR cable supplied with the 4300 transformer), as shown in Figure 5. These particular wires can be 24 gauge or larger, and can be run along with the AC and ground wires to the control panel.

  • Page 14: Installing Remote Keypads

    Section 3. INSTALLING REMOTE KEYPADS This section lists the wired keypads that may be used and provides instructions for wiring and mounting the keypads. A preliminary check-out procedure is also provided to ensure that the connected keypads are functioning properly in the system. Keypads That May Be Used ¥...

  • Page 15: Mounting The Keypads

    3. Connect remote Keypads for Partition 1 to terminals 4, 5, 6, and 7 on the control board, as shown in Figure 6. 4. Connect remote Keypads for Partition 2 to the 4-pin connector on the control board (see the Summary of Connections diagram for location of the 4-pin connector for partition 2).

  • Page 16: Preliminary Check-Out Procedure

    SUPPLEMENTARY CONTROL POWER SUPPLY TERMINAL STRIP – AUX AUX. DATA DATA – IMPORTANT: MAKE THESE CONNECTIONS DIRECTLY TO SCREW TERMINALS AS SHOWN. Figure 7. Using A Supplementary Power Supply For Keypads Preliminary Check-out Procedure If you want to check that the system is working before connecting field wiring from zones and devices, do the following: 1.

  • Page 17: Basic Hard-Wired Zones 1Ð8

    Section 4. BASIC HARD-WIRED ZONES 1–8 This section provides general information for the hard-wired zones in the system, plus specific instructions for installing 2-wire smoke detectors, 4-wire smoke/combustion detectors, and 2-wire latching type glass break detectors. Installing the Hard-Wired Zones Common Characteristics for Zones 1–8 ¥...

  • Page 18: Turning Off Fire Alarm Sounding

    Turning Off Fire Alarm You can turn off Fire alarm sounding by pressing the OFF key on any keypad or Sounding other arming/disarming device in that partition. To clear the "memory of alarm" and to reset the detectorÕs alarm, enter the security code plus OFF again. COMPATIBLE 2-WIRE SMOKE DETECTORS System Sensor System Sensor...

  • Page 19: Wiring 2-Wire Latching Type Glass Break Detectors On Zone 8

    COMPATIBLE 4-WIRE SMOKE/COMBUSTION DETECTORS 1412 System Sensor, 4-wire ionization products of combustion detector 2412 System Sensor, 4-wire photoelectric smoke detector 2412TH System Sensor, 4-wire photoelectric smoke detector w/135¼ F (57¼ C) heat detector A77Ð716B System Sensor, EOL relay module (supervisory module for wired 4-wire fire zone).

  • Page 20: Check-Out Procedure For Hard-Wired Zones

    Programming Hard-Wired Zones Each zone must be programmed into the system using the *56 Zone Programming mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to the Zone Response Type section and the Zone Programming section for specific instructions on programming hard-wired zones.

  • Page 21: Wired Zone Expansion (4219, 4229)

    Section 5. WIRED ZONE EXPANSION This section provides information regarding the use of expansion modules for expanding the number of wired zones in the system, the modules that can be used and their wiring connections. Installing Zone Expansion Units You can add an additional 8 wired EOLR zones to the basic control's 8 zones, for a total of 16 wired zones, by using a No.

  • Page 22: Check-Out Procedure For Wired Expansion Zones

    Programming Wired Expansion Zones Each zone must be programmed into the system using the *56 Zone Programming mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to the Zone Response Type section and the Zone Programming section for specific instructions on programming wired expansion zones.

  • Page 23: Wireless Zone Expansion (5800 System)

    Section 6. WIRELESS EXPANSION (5800 SYSTEM) This section provides instructions for installing 5800 series wireless receivers and transmitters. General Information In addition to its basic wired zones, the control supports up to 30 wireless zones using an appropriate 5881 (5882 in Canada) type RF receiver. The actual number of zones supported depends on whether you are using a wired zone expander module.

  • Page 24: Installation And Setup Of The 5881/5882 Receiver

    Installation and Setup of the 5881/5882 Receiver 1. Set the receiver's DIP switch for device address Ò0Ó, as described in its instructions (all switches to the right. . . ÒoffÓ). 2. Mount the receiver. The RF receiver can detect signals from transmitters within a nominal range of 200 feet.

  • Page 25: Installing The 5800Tm Module

    Terminal 6 YELLOW (Data from Control) Terminal 7 BLUE: Not Used Do not cut any of the jumpers on the 5800TM when using it with the FA162C. For additional information, refer to the 5800TMÕs instructions. 5800 Series Transmitters General 5800 series transmitters have built-in serial numbers that must be "enrolled"...

  • Page 26: Transmitter Input Types

    Transmitter Input Types All of the transmitters described have one or more unique factory assigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5803's three inputs require three programming zones). See APPENDIX A toward the end of this manual. Transmitters can be enrolled as one of the following types: Type Description...

  • Page 27: 5800 Series Transmitters Table

    5800 Series Transmitters Table Also refer to APPENDIX A near end of this manual for transmitter input loops/button locations. Model Description Input Type And Special Notes 5801 Wireless Panic ¥ Unit has 4 pushbuttons, each with a unique Input (loop) code. Transmitter ¥...
  • Page 28 Installing 5800 Series Transmitters To be sure reception of the transmitter's signal at the proposed mounting location is adequate, perform a Go/No Go test. Go/No Go Test Mode The Go/No Go tests will verify adequate RF signal strength from the proposed transmitter location, and allow you to reorient or relocate transmitters if necessary, before mounting the transmitters permanently.

  • Page 29: Relay Outputs & Powerline Carrier Devices

    ÊÊSection 7. ÊÊÊÊRELAY OUTPUTS & POWERLINE CARRIER ÊDEVICES Relay/Powerline Carrier Device Basics Relays and Powerline Carrier devices (ex. X-10 brand devices) are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications.

  • Page 30: Powerline Carrier Devices

    4229 RELAY DIP SWITCH RELAY CONNECTOR FOR SETTING ADDRESS AND ZONE “A” RESPONSE EITHER OR BOTH CAN BE USED TERMINALS ON RELAY CONTROL PANEL NO C NC 4-PIN CONSOLE PLUG GRN DATA OUT (TERM 6) TAMPER JUMPER POSITION TO CONTROL 4229 IN CABINET (–) GROUND (TERM 4)

  • Page 31: Wiring Connections

    Wiring Connections 1. Splice one end of a 3-conductor cable to the wire ends of the 4142TR cable supplied with the 4300 transformer. 2. Connect the 4142TR cable plug to the 9-pin connector on the control (see SUMMARY OF CONNECTIONS diagram for location of the 9-pin connector).

  • Page 32: Fa4285 Phone Module

    Module Installing the Phone Module General Information The FA4285 Phone Module is an add-on accessory for the FA162C that permits access to the security system via a Touch-tone phone (either on premises or by a call-in when away). The Phone Module can announce many of the same words that would normally be displayed on an Alpha keypad under the same system conditions.

  • Page 33: Phone Module Wiring

    Phone Module Wiring The FA4285 is wired between the control panel and the premises handset(s). It listens for touch tones on the phone line and reports them to the control panel. During on-premises phone access, it powers the premises phones; during off-premises phone access, it seizes the line from the premises phones and any answering machines.

  • Page 34: Figure 16.Êêfa4285 Phone Module Wiring Connections

    FA4285 WIRING NOTES: 1. Wire the FA4285 Phone Module exactly as shown, using a direct-connect cord and RJ31X jack. 2. If Touch-tones are not heard when pressing keys following phone access to the security system via an on-premises phone, try reversing the pair of wires connected to terminals 3 & 4 on the FA4285, and the pair of wires connected to terminals 21 &...

  • Page 35: Checking The Operation Of The Fa4285 Phone Module

    Programming the FA4285 Phone Module The system must be programmed for use with the FA4285 Phone Module, including assigning a phone code and selecting words from the alpha vocabulary. Refer to the Programming sections for specific programming details. Checking the Operation of the FA4285 Phone Module To Check Phone Module Operation From an On-Premises Phone: 1.

  • Page 36: External Sounders

    Section 9. EXTERNAL SOUNDERS This section provides a list of compatible sounders and connection information for an external sounder. Compatible Sounders AB-12M 10Ó Motorized Motor bell & box. UL Grade A. 100 mA Bell & Box current draw. 1011BE12M 10Ó Motor bell &...

  • Page 37: Sounder Connections

    Sounder Connections The FA162C provides a 12 VDC output which can power external alarm sounders (bells or sirens, see compatible sounders listed previously). This output will activate a sounder when an alarm occurs in partition 1 or 2. Make connections to alarm output terminals 3 (+) and 4 (Ð). See Figure 17.

  • Page 38: Section 10. Long Range Radio

    Section 10. LONG RANGE RADIO General Information Check availability of Models 7720 PLUS or 7820 long range radios. If output to long range radio is selected, all messages that are programmed to go to the primary telephone line receiver will also be sent to the 7720 PLUS or 7820 long range radio.

  • Page 39: Section 11. Audio Alarm Verification (Aav) Unit

    Section 11. AUDIO ALARM VERIFICATION (AAV) UNIT General Information An Audio Alarm Verification (AAV) module, such as the Eagle 1241, is an add-on accessory that permits voice dialog between an operator at a central station and a person at the alarm installation, for the purpose of alarm verification.

  • Page 40: Figure 20.Êêconnection Of Aav Unit Without An Fa4285 Phone Module

    INCOMING TELCO LINE DIRECT CONNECT CORD RJ31X RING JACK PREMISES ANSWERING MACHINE AND PLUG PHONES ANSWERING TERMINALS MACHINE ON CONTROL EARTH GROUND REFER TO AAV MODULE INSTRUCTIONS FOR CONNECTIONS TO AUDIO SPEAKERS AND MICROPHONE INPUT TRIGGER EAGLE SECURITY RING (TO TERM. 22 ) MODEL 1241 TIP (TO TERM.

  • Page 41: Section 12. Final Power Up

    Section 12. FINAL POWER UP This section provides information about final power-up procedures and battery size calculations. Earth Ground Connections The designated earth ground terminal (25) must be terminated in a good earth ground for the lightning transient protective devices in this product to be effective.

  • Page 42: Making The Battery Connections

    Making the Battery Connections 1. Use the battery standby formula (above) to select the appropriate battery for the installation. Do not connect the battery until all devices have been wired to the control. 2. Attach the Red and Black wires on the battery connector cable as follows: a) Red to the positive (+) battery tab on the control board.

  • Page 43: Section 13. Mechanics Of Programming

    Section 13. MECHANICS OF PROGRAMMING This section provides information on how to use the system's programming modes. It will enable you to understand how to enter and exit programming mode, and how to program the data fields and how to use the user-friendly interactive modes ( 56, 80, 81, 82, 83).

  • Page 44: Reviewing A Data Field/Erasing An Entry In A Data Field

    Reviewing a Data Field/Erasing an Entry in a Data Field Press [#] plus Field No. Data will be displayed for that field number. No changes will be accepted in this mode. To delete an entry in a field, press [ ] plus Field No. + [ ]. (Applies only to fields 40Ð...

  • Page 45: Section 14. Zone Response Type Definitions

    Section 14. ZONE RESPONSE TYPE DEFINITIONS General Information You must assign a zone type to each zone, which defines the way in which the system responds to faults in that zone. Zone types are defined below. Type 00 Program a zone with this zone type if the zone is not used. Zone Not Used Type 01 This zone type provides exit and entry delays whenever the zone is faulted if...
  • Page 46 Type 06 This zone type sends a report to the Central Station but provides no keypad display or sounding. This zone type is usually assigned to a zone containing 24-hour Silent Alarm an Emergency button. Type 07 This zone type sends a report to the Central Station, and provides an alarm sound at the keypad, and an audible external alarm.

  • Page 47: Section 15. Data Field Descriptions

    Section 15. DATA FIELD DESCRIPTIONS Descriptions of System Data Fields THE BLANK PROGRAMMING FORM SHOULD BE USED TO RECORD THE DATA FOR THIS INSTALLATION Defaults (where applicable) Are Indicated In Text The following pages list all data fields in this control (in numerical order). If you have performed the programming instructions that were included with the installation of each of the various peripheral devices covered in previous sections, this table will simply serve as a reference for all data fields in the system.
  • Page 48 POWERLINE CARRIER DEVICE (X-10) HOUSE ID ÊÊ0Ê Powerline Carrier devices require a House ID. This field identifies this House ID to the control. If Powerline Carrier devices are used, they are selected in field House ID is entered in following manner: 0 = A, 1 = B, 2 =C, 3 = D, 4 = E, 5 = F, 6 = G, 7 = H, 8 = I, 9 = J, # + 10 = K, # + 11 = L, # + 12 = M, # + 13 = N, # + 14 = O, # + 15 = P.
  • Page 49 ALARM BELL TIMEOUT ÊÊ1ÊÊ 0 = No timeout 1 = 4 min 2 = 8 min 3 = 12 min 4 = 16 min This field determines whether the external sounder will shut off after time allotted, or continue until manually turned off. UL installations: must be set for a minimum of 4 min (option 1) EXIT DELAY Ê7Ê|Ê0Ê...
  • Page 50 DIALER PABX ACCESS CODE (See Box at Left) ÊÊÊÊ|ÊÊÊ|ÊÊÊÊ|ÊÊÊÊ|ÊÊÊ|ÊÊÊÊ PROGRAMMING Enter up to 6 digits if PABX is needed to access an outside line. If ( 40Ð 50) fewer than 6 digits are needed to be entered, exit by pressing [ ] and next field number (e.g., 41).
  • Page 51 SPLIT/DUAL REPORTING Ê ÊÊ0ÊÊ Use options 0 - 5 when reporting to standard telephone receivers TO PRIMARY TO SECONDARY All reports none, unless primary fails, then all Alarms, Restore, Cancel Others All except Open/Close, Test Open/Close, Test Alarms, Restore, Cancel All except Open/Close, Test All reports Use options 6 - 9 when reporting to a pager is desired...
  • Page 52 TEST REPORT OFFSET Ê ÊÊ2Ê 0 = 24 hours after exiting program mode or download 1 = 6 hours after exiting program mode or download 2 = 12 hours after exiting program mode or download 3 = 18 hours after exiting program mode or download This is the time to first report from programming or downloading.
  • Page 53 SYSTEM STATUS EXIT ERROR REPORT CODEÊ (See box on previous page) Ê ÊÊ0ÊÊ REPORT CODES If the system is armed and an Entry/Exit or Interior zone is still open ( 59Ð 68) after the exit delay time has expired, an alarm will sound at the keypad and external sounder (keypad also displays ÒExit AlarmÓ).
  • Page 54 RF XMTR LOW BATTERY REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ This is sent in the event that a wireless transmitter low battery condition exists. (See box) CANCEL REPORT CODEÊÊÊÊ(See box on previous page.)ÊÊ ÊÊ0ÊÊ|ÊÊ0ÊÊ This is sent upon disarming of the system after an alarm condition was reported.
  • Page 55 EVENT LOGGING (continued) The FA162C system has the ability to record various events in a history log (48-event capacity). The types of events to be logged can be selected as indicated. At any time, the downloader operator can then upload the log and view or print out all or selected categories of the log.
  • Page 56 RING DETECTION COUNT FOR DOWNLOADING Ê ÊÊ0ÊÊ 0-15 = number of rings before control picks up phone line Refer to the chart below and program this field accordingly. NOTE: If "15" is ÊPhone Answering entered in field *95 to Module ÊÊMachine Downloading Field...

  • Page 57: Section 16. Zone Programming (*56 Menu Mode)

    Section 16. ZONE PROGRAMMING (*56 Menu Mode) While in program mode, press 56 to enter Zone Programming Menu Mode. Refer to the zone assignment table for 56 on the separate programming form . This is an interactive menu mode that is used to program zone numbers, zone types, partition numbers, alarm and report codes, and to identify the type of loop input device.
  • Page 58 Zone Number (Zn): Enter the zone number that you wish to Enter Zn Num. program (or 00 to exit zone programming). Press [ ] to continue. (00 = Quit) Zone 10 entered A summary display appears, showing the status of that zone's Zn ZT P RC In: L programming.
  • Page 59 Loop number (LP#): Enter the loop number (1-4) for the zone of the 10 INPUT DEV: LP# transmitter being enrolled. The default is loop "1." To accept this, RF TRANS. RF: 1 press [ ]. If a different loop number is being used on this transmitter, enter the desired loop number and press [ ] to continue (see the transmitter's Installation Instructions for specific loop designations).
  • Page 60 Ê The summary screen for the zone will appear. Note that an "s" ZN ZT P RC IN: L indicates that a serial number has, in fact, been enrolled. The cursor 10 03 1 3C RF: 1 s will be flashing above the loop number. Press [ ] to accept the zone information.

  • Page 61: Section 17. Output Device Programming (*80 Menu Mode)

    Section 17. OUTPUT DEVICE PROGRAMMING (*80 Menu Mode) Programming Options Defined The following will help you understand the programming of Output Devices when using 80 and 81 modes. The options used to start and stop these devices are described below, followed by the actual screen prompts and available entries.
  • Page 62 If a "SYSTEM OPERATION" is chosen (e.g., End of Exit Time), that operation will cause the device to activate as selected in "ACTION.Ó The different choices for "ZONE TYPE" and "SYSTEM OPERATION" are listed in ÒProgramming Output Relays & Powerline Carrier devicesÓ later in this section, and in the Programming Form.
  • Page 63 Programming Output Relays and Powerline Carrier Devices While in program mode, press 80 to enter Output Device Menu Mode. This mode is used to program all output devices used in the system (4229 or 4204 Relay modules, or Powerline Carrier devices). Refer to the output device table for 80 on the separate programming form when...
  • Page 64 Enter (if applicable) the partition number 1 or 2 (or 0 for any). 02 Start: Part Press the [ ] key to continue. Any Partition If a zone list will be used to STOP, or restore, the device action, enter the zone 02 Stop: Zn List list number 1, 2, or 3 (to be programmed in 81 mode).

  • Page 65: Section 18. Zone Lists (*81 Menu Mode)

    Section 18. ZONE LISTS (*81 Menu Mode) While in program mode, press 81 to enter Zone List Menu Mode. This mode is used to program zone lists for output devices (programmed in menu mode) and/or for defining a common zone. Refer to the Programming Form worksheet for 81 Mode.

  • Page 66: Section 19. Alpha Description Programming (*82 Menu Mode)

    . The Phone Module will not provide annunciation of the other words. If a FA4285 Phone Module is added to an existing FA162C system, the Alpha descriptors presently in the system should be re-programmed, selecting from those words shown in boldface type in the Alpha Vocabulary list.
  • Page 67 Summary Mode Display If a descriptor was not entered Default DescriptorÊ previously for zone 1, the default ZN 0 1 ZO NE 0 1 descriptor for zone 1 will be displayed. Note that this a Òsummary modeÓ, and that no entries can be made. Entries can be made only when the display contains a flashing cursor, which signifies the Òentry modeÓ.
  • Page 68 Ê9. Press Ò6Ó to accept the selected ZN 0 1 BA CK ÊÊword. DO O R ÊÊÊ ÊNOTE: If these are the only words you ÊÊare using for the descriptor, press Ò8 Ó ÊÊinstead of Ò6 Ó to save them Flashing Cursor if Ò6Ó...

  • Page 69: Adding Custom Words

    Adding Custom Words (will not be annunciated by FA4285 Phone Module) You can add up to 10 installer-defined words to the built-in vocabulary. Each of the 10 "words" can actually consist of a "word string" of one or more words, but no more than ten characters can be used for each word or word string.

  • Page 70: Alpha Vocabulary List (For Entering Zone Descriptors)

    ALPHA VOCABULARY LIST (For Entering Zone Descriptors) NOTE: The list below is a revised vocabulary list which differs from earlier versions of the FA160C. Use only this list when programming FA162C zone descriptors. (Word Space) ¥ 064 DUCT ¥ 114 LOADING ¥...

  • Page 71: Section 20. Using Sequential Mode (*83 Menu Mode)

    Section 20. USING 83 SEQUENTIAL MODE Use 83 Sequential mode when a wireless transmitter is to be physically added, removed, or simply changed (as when replacing a unit that has a non-removable battery). By using this mode, you can add, delete, or change the serial number of a transmitter in a zone, but retain all other existing data that has been programmed for that zone.
  • Page 72 5. This prompt is displayed when the system has found the next zone 10 INPUT S/N: L which needs to be enrolled. The system will respond to the first serial Axxx xxxx number transmitted after the [ ] key on the keypad is pressed. A serial number may be enrolled by one of two methods: a) Enter the 7 digit serial number printed on the transmitter b) Activate the transmitter by faulting or restoring the input you wish...
  • Page 73 When the system sees activity on the appropriate input, it will beep 10 CONFIRMED three times and display the confirmation message. Press [ ] or the A022-4064 3 upper left-hand button of the program tool to when you are ready to enroll the next transmitter.

  • Page 74: Section 21. Remote Programming And Control (Downloading)

    Section 21. REMOTE PROGRAMMING AND CONTROL (DOWNLOADING) General Information The FA162C can be remotely programmed from an IBM compatible Personal Computer (PC) , a HAYES Modem, and First Alert Professional FADL Software (as specified below). Downloading may only be performed if a technician is at the site.

  • Page 75: Remote Programming Information

    Remote Programming Information The downloading system can perform many functions when in communication with the control unit. Besides uploading and downloading, the status of the system can be observed and various commands can be initiated, as follows: · Arm the System in the Away Mode; Disarm the System. ·...

  • Page 76: Section 22. System Communication

    Section 22. SYSTEM COMMUNICATION This section provides an explanation of formats this system accommodates for reporting alarms and other system conditions to the central station. The process of a successful transmission consists of both the method of communication between the control panel and the central station receiver and the actual way the information is sent and displayed at the central station.
  • Page 77 The following describes each format in greater detail. 3+1 and 4+1 Standard Formats Comprise a 3- (or 4-) digit subscriber number and a single digit report code (e.g. Alarm, Trouble, Restore, Open, Close, etc). 3+1 and 4+1 Expanded Formats Comprise a 3- (or 4-) digit subscriber number, and a two-digit report code.

  • Page 78: Table Of Contact Id Codes

    Ademco Contact ID Reporting takes the following format: CCCC Q EEE GG ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where: E = new event , and R = restore EEE = Event code (3 hexadecimal digits) Note: For a complete list of event codes, refer to the central office receiver manual.

  • Page 79: Section 23. System Operation

    ÊÊÊ Section 23. SYSTEM OPERATION Security Codes Installer Code The installer programs the 4-digit Installer Code initially as part of the programming procedure. The factory default Installer code is " 4-1-1-2 ", but may be changed in field 20. The Installer code is the only code that can enter programming mode and also, in normal operation mode, is used to enter the Master code for each partition, which allows access to the normal functions of the system.

  • Page 80: Keypad Functions

    Keypad Functions General Information Note that if you enabled QUICK ARM for the partition (field 21), the [#] key can be pressed instead of entering the partition's security code, for any of the arming procedures (Away, Stay, Instant, Maximum, etc.). The security code is always required, however, when disarming the system.
  • Page 81 If the local partition (at which the arming is attempted) is not Ready To Arm, one beep will sound after [AWAY] is pressed, and neither partition will arm. If the remote (other) partition is not Ready To Arm, two beeps will sound after the first press of [AWAY], and a single beep will sound after the second [AWAY] is pressed, and neither partition will arm.

  • Page 82: Trouble Conditions

    Trouble Conditions (See Troubleshooting Guide also) General Information The word "CHECK" on the Keypad's display, accompanied by a rapid "beeping" at the Keypad, indicates that there is a trouble condition in the system. The audible warning sound can be silenced by pressing any key. Instruct users to call for service immediately upon seeing any of the following messages.

  • Page 83: Section 24. Testing The System

    Section 24. TESTING THE SYSTEM Test Procedure After installation is completed, each partition of the Security System should be carefully tested, as follows. 1. With the System in the disarmed state, check that all zones are intact. If a NOT READY message is displayed, press the [ ] key to display the faulted zone(s).

  • Page 84: To The Installer

    ¥ When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other buttons on that transmitter are cleared. This also applies to 5816 and 5817 transmitters which have multiple loops (zones). ¥ Any transmitter that is not ÒenrolledÓ will not turn off its zone number. Exit this mode by keying Installer code + OFF.

  • Page 85: Section 25. Troubleshooting Guide

    1a. Transmitter or 5881/5882 not properly Check or change transmitter's battery. received at 5881/5882. powered. Check FA162C's AC power. 1b. If Transmitter is 5827/5827BD , house code 1b. Check code switches inside transmitter. not set in field * 24, or transmitter not set Must match with RF House Code programmed in FA162C.
  • Page 86 2d. Program prefix or access code into the prefix or access code. FA162C. 2e. Telephone call to central monitoring 2e. FA162C system cannot work in this station requires operator assistance. situation. Does not arm properly. 3a. Ready light not on.

  • Page 87: Contacting Technical Support In The Event Of Problems

    ¥ Note the proper model number of this product, and the version level (if known) along with any documentation that came with the product. ¥ Note your First Alert customer number and/or company name. Having this information handy will make it easier for us to serve you quickly and effectively.

  • Page 88: Regulatory Agency Statements

    REGULATORY AGENCY STATEMENTS UL NOTICE: This is a "Grade A" residential system. FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.

  • Page 89: Section 26. Specifications & Accessories

    Section 26. SPECIFICATIONS & ACCESSORIES Specifications FA162C 1. Physical: 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm) SECURITY 2. Electrical: CONTROL VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321 (in U.S.A.) RECHARGEABLE BACK-UP BATTERY: 12VDC, 4AH (Gel type).
  • Page 90 200ft (60m) nominal indoors from wireless transmitters (the actual range to be determined with system in TEST mode). 4. Zones: (With the Ademco FA162C ) 5881L/5882L: accepts up to 8 transmitters 5881M/5882M: accepts up to 16 transmitters 5881H/5882H: accepts up to 24 transmitters 5800TM 1.

  • Page 91: Accessories (Compatible Devices)

    Accessories (Compatible Devices) No. 1321 16.5VAC, 25VA Plug-In Transformer No. 4300 Powerline Carrier device Interface AC Transformer Sounders Ademco AB-12M 10Ó Motor bell & box. UL Grade A. 100 mA current Motorized Bell & Box draw. Ademco 1011BE12M 10Ó Motor bell & box. UL Listed. 100 mA current Motorized Bell &...

  • Page 92: Appendix A. 5800 Rf System Wireless Transmitters, Input Loop Identification Diagrams

    APPENDIX A. 5800 RF System Wireless Transmitters Transmitter Input Loop Identification 5800 Series Transmitter Input Loop Identification ¥ All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the input loops requires its own programming zone (e.g., a 5803's three inputs require three programming zones).

  • Page 93: Index

    INDEX 1-minute delay .............. 41 6138 ............... 7, 14, 15, 90 1011BE12M ..............36 6139 ............. 7, 9, 14, 15, 43, 90 1321 ............8, 9, 12, 30, 41 6139TRK ............... 15 1400 ................91 702 ................. 91 1412 ................91 705Ð820 .................
  • Page 94 Cabinet Lock ..............10 IBM Compatible Personal Computer (PC) ....74 Caller ID unit ............33, 34 IBM Personal Computer ..........43 Cancel Report Code ............54 Ideal Model 61Ð035 ..........13, 41 Central Station ............. 52 IEI 735L series detectors ..........19 Character (Ascii) Chart ..........
  • Page 95 Program Upload or Download Time ......75 Trouble Report Code ............ 53 Programming Information ........... 43 Trouble Restore Report Code ........54 Pulse Dialing, ..............32 UL ........13, 15, 25, 36, 38, 42, 88, 89 Quick Arm ............43, 47, 80 Unsupervised RF ............
  • Page 96 Ð NOTES Ð – 96 –...
  • Page 97 Ð NOTES Ð – 97 –...

  • Page 98: Limitations Of This Alarm System

    WARNING THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example: ¥...

  • Page 99: Summary Of Connections

    BATTERY FUSE ADEMCO No. 4219 SET UNIT’S DIP GEL LEAD ACID TYPE. WIRED EXPANSION MODULE SWITCH FOR FOR REPLACEMENT, REMOTE BATTERY NORMALLY NEED NOT BE (8 ADD'L EOLR WIRED ZONES) DEVICE AUX PWR USE SAME VALUE KEYPAD 9-PIN CONNECTOR REPLACED FOR AT LEAST 3 YRS. ADDRESS OUTPUT -OR-...

  • Page 100: Limited Warranty

    Pittway Corporation, and its divisions, subsidiaries and affili ates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its First Alert products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and...
