3.8 PoE power output

The IP Buddy+ supports PoE (Power over Ethernet) output to an IP camera via the LAN port. Data transmission and
48VDC use the network cable's 1, 2, 3, and 6 pins to deliver power. If the IP camera supports PoE, you can directly connect
to the camera without the use of an external power supply.
Note: Please make sure a network cable is connected to the IP Buddy+'s LAN port ONLY. Before using the PoE power
output, please make sure the IP camera supports PoE power, otherwise it will damage the IP camera.

3.9 12VDC 2A power output

When the IP Buddy+ is turned on, the 12VDC power output ON by default. The smaller end of the supplied converter
cable connects to the tester's DC12V/2A OUTPUT and the other end connects to the camera's power input.
Note:
Don't input any power into the "DC12/2A OUTPUT" port of the tester. Such damage will void the warranty.
a.
The IP BUDDY+'s power output capacity is 2A. If the IP camera uses more than 2A, the tester will automatically enter
b.
a protection mode. Disconnect all cables from the tester and reboot it to resume using the tester.
Make sure the tester has a sufficient charge otherwise the tester will not able to provide enough output power.
c.
Page.35.
